PC200-8M0 S/N Y201001-UP

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	6754111211	CYLINDER HEAD ASSEMBLY	1	Field_2: 26594007 \| Field_5: 1 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?		HEAD ASSEMBLY	1	Field_2: 26594007 \| Field_4: C1 \| Field_5: 2 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?		CYLINDER HEAD	1	Field_2: 26594007 \| Field_4: C1 \| Field_5: 3 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754111170	INSERT{INTAKE VALVE}	12	Field_2: 26594007 \| Field_5: 4 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754111180	INSERT{EXHAUST VALVE}	12	Field_2: 26594007 \| Field_5: 5 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754111150	PLUG	7	Field_2: 26594007 \| Field_5: 6 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6732211820	PLUG	13	Field_2: 26594007 \| Field_5: 7 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6735215531	PLUG,EXPANSION	11	Field_2: 26594007 \| Field_5: 8 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6744111070	PLUG	2	Field_2: 26594007 \| Field_5: 9 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754111160	PLUG	2	Field_2: 26594007 \| Field_5: 10 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6732211981	PLUG,PIPE	4	Field_2: 26594007 \| Field_5: 11 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6732111920	PLUG	3	Field_2: 26594007 \| Field_5: 12 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6732612240	PLUG	1	Field_2: 26594007 \| Field_5: 13 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6216146820	PLUG ASSEMBLY	1	Field_2: 26594007 \| Field_5: 14 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6216146860	ORING	1	Field_2: 26594007 \| Field_5: 15 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414541	SEAL	12	Field_2: 26606274 \| Field_5: 16 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414540	SEAL	12	Field_2: 26594007 \| Field_3: 26606273 \| Field_5: 17 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414100	VALVE KIT{INTAKE}	12	Field_2: 26594007 \| Field_5: 18 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414110	VALVE	1	Field_2: 26594007 \| Field_5: 19 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6744111020	COLLET	2	Field_2: 26594007 \| Field_5: 20 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414540	SEAL	1	Field_2: 26649437 \| Field_5: 21 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414541	SEAL	1	Field_2: 26605347 \| Field_3: 26649436 \| Field_4: A1 \| Field_5: 22 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414540	SEAL	1	Field_2: 26594007 \| Field_3: 26605346 \| Field_5: 23 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414200	VALVE KIT{EXHAUST}	12	Field_2: 26594007 \| Field_5: 24 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414210	VALVE	1	Field_2: 26594007 \| Field_5: 25 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6744111020	COLLET	2	Field_2: 26594007 \| Field_5: 26 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414440	SPRING	24	Field_2: 26665330 \| Field_5: 27 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414432	SPRING	24	Field_2: 26620881 \| Field_3: 26665329 \| Field_5: 28 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414431	SPRING	24	Field_2: 26620244 \| Field_3: 26620880 \| Field_5: 29 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414430	SPRING	24	Field_2: 26594007 \| Field_3: 26620243 \| Field_5: 30 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754414510	RETAINER	24	Field_2: 26594007 \| Field_5: 31 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754111610	BOLT	26	Field_2: 26594007 \| Field_5: 32 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD
?	6754111811	GASKET	1	Field_2: 26594007 \| Field_5: 33 \| Field_6: X160B90020 \| Field_7: CYLINDER HEAD

Komatsu PC200-8M0 S/N Y201001-UP parts catalog PDF

CYLINDER HEAD (|AA00005) in PC200-8M0 S/N Y201001-UP. Diagram image and parts list.
