PC300LC-8M0 S/N Y301001-UP

Komatsu parts book diagram for PC300LC-8M0 S/N Y301001-UP: EXHAUST MUFFLER AND DRAIN PIPING

1 2 3 4 6 5 6 7 12 11 5 11 8 9 10 12

	#	Part Number	Partname	Quantity	Options	Reference
	1	207-01-71310	DAMPER	1	Field_2: 26866736 \| Field_5: 1 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	2	01010-81225	BOLT	8	Field_2: 26866736 \| Field_5: 2 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	3	01643-31232	WASHER	8	Field_2: 26866736 \| Field_5: 3 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	4	6745-11-6530	TUBE	1	Field_2: 26866736 \| Field_5: 4 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	5	6991-11-5990	CLAMP	2	Field_2: 26866736 \| Field_5: 5 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	6	01435-01016	BOLT	2	Field_2: 26866736 \| Field_5: 6 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	7	6745-11-8260	BRACKET	1	Field_2: 26866736 \| Field_5: 7 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	8	6745-11-8270	BRACKET	1	Field_2: 26866736 \| Field_5: 8 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	9	01010-81240	BOLT	10	Field_2: 26866736 \| Field_5: 9 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	10	01643-31232	WASHER	10	Field_2: 26866736 \| Field_5: 10 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	11	01010-81245	BOLT	2	Field_2: 26866736 \| Field_5: 11 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING
	12	01643-31232	WASHER	2	Field_2: 26866736 \| Field_5: 12 \| Field_6: X21-2227630 \| Field_7: EXHAUST MUFFLER AND DRAIN PIPING

Komatsu PC300LC-8M0 S/N Y301001-UP parts catalog PDF

EXHAUST MUFFLER AND DRAIN PIPING (|AA00001) in PC300LC-8M0 S/N Y301001-UP. Diagram image and parts list.
