HYDRAULIC CYLINDER COLD WEATHER DESIGN | PC5500-6 S/N 15166

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC5500-6 S/N 15166

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	934 650 40	Hydraulic cylinder assy. fig-nos: 02-37	1
?		Cylinder barrel	1
?	798 085 73	Cylinder barrel cpl., fig-nos: 03,05,36,37	1
?	960 213 40	Freeze-in bush	1
?	004 860 98	Nipple	4
?	947 188 40	Thread pin	1
?	947 197 40	Groove nut	1
?	324 905 40	Piston guide	2
?	950 384 40	Piston guide	6
?	324 465 40	O-ring	1
?	324 468 40	Seal	1
?	929 277 40	Piston assy. fig-nos. 13 and 14 (finish work after bush is (installed)	1
?	395 620 40	Piston bush (no field repair item)	1
?		Piston	1
?	517 812 98	O-ring	1
?	907 993 40	Support ring	2
?	504 779 98	O-ring	1
?	324 467 40	Support ring	1
?	953 861 40	Sealing flange fig-nos: 20 and 21 (finishing after bush is installed)	1
?		Bush	1
?	953 859 40	Bush (Only for work shop repair)	1
?	514 759 98	Screw cold weather design	28
?	324 463 40	Seal kit	1
?	906 593 40	Support ring	1
?	909 524 40	Cover	1
?	502 572 98	Screw cold weather design	12
?	906 544 40	Stripper	1
?	501 352 98	Feather key	1
?	794 780 73	Piston rod assy. fig-nos: 04,05,30,37	1
?		Piston rod	1
?	430 924 40	Half shim	12
?	909 526 40	Cover ring	1
?	906 732 40	Support ring fig. no. 27	1
?	960 214 40	Freeze in bushing	1
?	907 026 40	Pin seal ring	4
?	793 621 73	Seal kit for piston fig-nos. 08-11,15 and 16	1
?	793 622 73	Seal kit for sealing flange, with slited seals, fig-nos: 17,18,23,24,27 and 35	1
?	797 326 73	Seal kit for sealing flange, with non slited seals, fig-nos: 17,18,23,24,27 and 35	1
