01 |
|
Drive gear box |
1 |
InternBDB: 655 639 40 | InternKon: 575 655 40 / 6
|
991-0194a |
|
|
|$2 |
763 528 73
|
Drive gear box-mounting kit |
1 |
InternBDB: E-ST
|
|
|
|
02 |
|
Drive motor |
2 |
InternBDB: 461 947 40 | InternKon: 575 655 40 / 7
|
090-0563a |
|
|
03 |
674 029 40
|
Drive sprocket set fig-nos. 25-27 |
1 |
InternBDB: DKG | InternKon: 575 655 40 / 4
|
|
|
|
03 |
675 810 40
|
Drive sprocket set, oversize fig-nos. 25-27 |
1 |
InternBDB: DKG
|
|
|
|
04 |
643 970 40
|
Drive sprocket ring |
1 |
InternKon: 575 655 40 / 58
|
|
|
|
05 |
512 046 98
|
Bolt Cold weather design |
85 |
InternBDB: M36x260 | InternKon: 575 655 40 / 49
|
|
|
|
06 |
255 056 40
|
Washer |
242 |
InternBDB: Ш 37 | InternKon: 575 655 40 / 27
|
|
|
|
07 |
501 124 98
|
Nut |
85 |
InternBDB: M 36 /934 | InternKon: 575 655 40 / 55
|
|
|
|
08 |
323 460 40
|
Vent valve |
1 |
InternKon: 575 655 40 / 11
|
|
|
|
09 |
307 454 99
|
Bolt |
16 |
InternBDB: M16x50 | InternKon: 575 655 40 / 54
|
|
|
|
10 |
316 211 99
|
Washer |
16 |
InternBDB: Ш 17 | InternKon: 575 655 40 / 31
|
|
|
|
12 |
511 819 98
|
Bolt Cold weather design |
12 |
InternBDB: M30x80 | InternKon: 575 655 40 / 53
|
|
|
|
13 |
255 057 40
|
Washer |
12 |
InternBDB: Ш 31 | InternKon: 575 655 40 / 28
|
|
|
|
15 |
515 291 98
|
Bolt Cold weather design |
72 |
InternBDB: M36x210 | InternKon: 575 655 40 / 50
|
|
|
|
20 |
567 090 40
|
Track frame, r.h. |
1 |
InternBDB: SK 561 490 40 | InternKon: 575 645 40 / 5
|
|
|
|
21 |
567 310 40
|
Track frame, l.h. |
1 |
InternBDB: SK 567 300 40 | InternKon: 575 655 40 / 5
|
|
|
|
25 |
661 656 40
|
Guard plate l.h. |
1 |
InternBDB: 771x955 | InternKon: 675 538 40 / 1
|
|
|
|
26 |
675 540 40
|
Angle |
2 |
InternBDB: H455E | InternKon: 675 538 40 / 2
|
|
|
|
27 |
661 657 40
|
Guard plate r.h. |
1 |
InternBDB: 771x955 | InternKon: 675 538 40 / 3
|
|
|
|
28 |
675 543 40
|
Angle |
2 |
InternBDB: H455E | InternKon: 675 538 40 / 4
|
|
|
|
29 |
307 826 99
|
Bolt |
6 |
InternBDB: M16x50/8.8/ 933 | InternKon: 675 538 40 / 5
|
|
|
|
30 |
340 469 99
|
Washer |
6 |
InternBDB: Ш 17/ 125 | InternKon: 675 538 40 / 6
|
|
|
|
31 |
334 601 99
|
Nut |
6 |
InternBDB: M 16 /985 | InternKon: 675 538 40 / 7
|
|
|
|
32 |
883 900 40
|
Retainer |
2 |
InternKon: 675 538 40 / 8
|
|
|
|
35 |
|
Drive sprocket element, 5 teeth
These parts are not sold
separately |
1 |
InternBDB: DKG 674 024 40
|
|
|
|
36 |
|
Drive sprocket element, 5 teeth
These parts are not sold
separately |
1 |
InternBDB: DKG 674 026 40
|
|
|
|
37 |
|
Drive sprocket element, 4 teeth
These parts are not sold
separately |
1 |
InternBDB: DKG 674 022 40
|
|
|
|
40 |
307 756 99
|
Bolt |
4 |
InternBDB: M8x30 / 933 / 8.8 | InternKon: 674 029 40 / 68
|
|
|
|
41 |
674 995 40
|
Driving performance meter |
1 |
|
|
