01 |
979 878 40
|
Housing |
1 |
|
|
|
|
03 |
999 301 40
|
Breaker 16A |
9 |
|
|
|
|
04 |
999 299 40
|
Breaker 10A |
27 |
|
|
|
|
05 |
999 296 40
|
Breaker 1A |
2 |
|
|
|
|
06 |
999 298 40
|
Breaker 6A |
8 |
|
|
|
|
07 |
999 305 40
|
Breaker 32A |
1 |
|
|
|
|
08 |
999 306 40
|
Breaker 40A |
1 |
|
|
|
|
09 |
999 307 40
|
Breaker 50A |
7 |
|
|
|
|
10 |
999 309 40
|
Circuit breaker 100A |
1 |
|
|
|
|
11 |
999 303 40
|
Breaker 25A |
1 |
|
|
|
|
12 |
999 819 40
|
Relay 120A |
1 |
|
|
|
|
13 |
999 818 40
|
Relay 75A |
2 |
|
|
|
|
14 |
100 031 42
|
Relais with retainer and bolts 40A |
2 |
|
|
|
|
15 |
963 818 40
|
Relay assy. 50A |
2 |
|
|
|
|
16 |
999 405 40
|
Distribution block |
2 |
|
|
|
|
17 |
960 613 40
|
Resistor array assy. |
1 |
|
|
|
|
18 |
951 284 40
|
Relay |
1 |
|
|
|
|
19 |
655 748 40
|
Diode array |
2 |
|
|
|
|
20 |
950 662 40
|
Cable shoe |
4 |
|
|
|
|
21 |
256 945 40
|
Cable shoe |
6 |
|
|
|
|
22 |
941 354 40
|
Cable shoe |
5 |
|
|
|
|
23 |
951 445 40
|
Semiconductor relay 10A |
1 |
|
|
|
|
24 |
951 916 40
|
Semiconductor relay |
5 |
|
|
|
|
26 |
951 862 40
|
Semiconductor relay 10A |
17 |
|
|
|
|
27 |
896 754 40
|
Switch modul |
1 |
|
|
|
|
28 |
999 850 40
|
Through clamp |
1 |
|
|
|
|
29 |
941 503 40
|
Cover plate |
1 |
|
|
|
|
30 |
941 502 40
|
Potencial clamp |
20 |
|
|
|
|
31 |
950 339 40
|
Wire clip |
1 |
|
|
|
|
32 |
906 612 40
|
Through clamp 2.5 |
62 |
|
|
|
|
33 |
906 613 40
|
Cover plate |
6 |
|
|
|
|
34 |
940 673 40
|
Clamp |
30 |
|
|
|
|
35 |
950 185 40
|
Protective wire clip |
28 |
|
|
|
|
36 |
344 498 40
|
Supporting trestle |
6 |
|
|
|
|
37 |
343 104 99
|
Lock washer |
6 |
|
|
|
|
38 |
340 504 99
|
Washer |
6 |
|
|
|
|
39 |
318 983 99
|
Screw |
6 |
|
|
|
|
40 |
999 407 40
|
Distribution block |
1 |
|
|
|
|
41 |
940 640 40
|
Sammelschiene Endkappe |
24 |
|
|
|
|
42 |
941 685 40
|
Group plate |
20 |
|
|
|
|
43 |
323 961 40
|
Sleeve 6,3x0,8 |
4 |
|
|
|
|
45 |
951 426 40
|
Slew measuring |
1 |
|
|
|
|
46 |
360 801 40
|
Marking strips |
2 |
|
|
|
|
47 |
906 623 40
|
Marking strip |
1 |
|
|
|
|
48 |
906 687 40
|
Marker 101?150 |
3 |
|
|
|
|
49 |
906 624 40
|
Marker 1?10 |
1 |
|
|
|
|
50 |
906 625 40
|
Marker 11?20 |
1 |
|
|
|
|
51 |
906 626 40
|
Marker 21?30 |
1 |
|
|
|
|
52 |
906 627 40
|
Marker 31?40 |
1 |
|
|
|
|
53 |
100 057 42
|
Cable 11X_10 |
1 |
|
|
|
|
56 |
950 620 40
|
Rail collector |
-2 |
|
|
|
|
62 |
974 058 40
|
Plug assy. |
7 |
|
|
|
|
63 |
974 059 40
|
Plug assy. |
4 |
|
|
|
|
64 |
990 641 40
|
Cable union |
1 |
|
|
|
|
65 |
517 324 98
|
Nut |
1 |
|
|
|
|
66 |
941 813 40
|
End pin |
2 |
|
|
|
|
68 |
518 546 98
|
Lock washer |
2 |
|
|
|
|
69 |
321 015 99
|
Bolt |
2 |
|
|
|
|
70 |
978 191 40
|
Gyrosensor assy. |
1 |
|
|
|
|
71 |
975 372 40
|
Harness switch cabinet 11X001 |
1 |
|
|
|
|
72 |
983 940 40
|
Harness switch cabinet 11X002 |
1 |
|
|
|
|
73 |
975 374 40
|
Harness switch cabinet 11X003 |
1 |
|
|
|
|
74 |
975 375 40
|
Harness switch cabinet 11X004 |
1 |
|
|
|
|
75 |
100 059 42
|
Harness switch cabinet 11X005 |
1 |
|
|
|
|
76 |
104 302 42
|
Harness switch cabinet 11X006 |
1 |
|
|
|
|
77 |
993 399 40
|
Harness switch cabinet 11X007 |
1 |
|
|
|
|
78 |
104 305 42
|
Harness switch cabinet 11X008 |
1 |
|
|
|
|
79 |
975 381 40
|
Harness switch cabinet 11X009 |
1 |
|
|
|
|
80 |
975 382 40
|
Harness switch cabinet 11X010 |
1 |
|
|
|
|
81 |
975 383 40
|
Harness switch cabinet 11X011 |
1 |
|
|
|
|
82 |
104 301 42
|
Harness switch cabinet 11X012 |
1 |
|
|
|
|
83 |
975 385 40
|
Harness switch cabinet 11X013 |
1 |
|
|
|
|
84 |
975 386 40
|
Harness switch cabinet 11X014 |
1 |
|
|
|
|
85 |
996 305 40
|
Harness switch cabinet 11X015 |
1 |
|
|
|
|
86 |
104 307 42
|
Harness switch cabinet 11X021 |
1 |
|
|
|
|
87 |
996 303 40
|
Harness switch cabinet 11X022 |
1 |
|
|
|
|
89 |
975 392 40
|
Harness switch cabinet 11X032 |
1 |
|
|
|
|
90 |
975 393 40
|
Harness switch cabinet 11X033 |
1 |
|
|
|
|
94 |
975 397 40
|
Harness switch cabinet 11X034 |
1 |
|
|
|
|
95 |
993 125 40
|
Harness switch cabinet 11X023 |
1 |
|
|
|
|
96 |
519 163 98
|
Receptacle |
6 |
|
|
|
|
97 |
519 603 98
|
Cable lug |
4 |
|
|
|
|
98 |
055 104 40
|
Cable lug 1,5 |
12 |
|
|
|
|
99 |
999 852 40
|
Cover plate |
1 |
|
|
|
|
100 |
951 901 40
|
Modul |
1 |
|
|
|
|
101 |
898 681 40
|
Relay assy. |
1 |
|
|
|
|
104 |
951 888 40
|
Isolationplate |
6 |
|
|
|
|
105 |
906 773 40
|
Cover plate |
1 |
|
|
|
|
111 |
978 193 40
|
Relay socket assy. |
2 |
|
|
|
|
112 |
999 740 40
|
Relay |
2 |
|
|
|
|
113 |
344 498 40
|
Supporting trestle |
2 |
|
|
|
|
114 |
318 983 99
|
Screw |
2 |
|
|
|
|
115 |
518 314 98
|
Lock washer |
2 |
|
|
|
|
116 |
519 164 98
|
Sleeve |
4 |
|
|
|
|
117 |
519 163 98
|
Receptacle |
4 |
|
|
|
|
118 |
323 179 40
|
Relay |
2 |
|
|
|
|
123 |
906 611 40
|
Mounting part |
1 |
|
|
|
|
124 |
604 733 40
|
Resistor 2 W |
15 |
|
|
|
|
125 |
969 833 40
|
Cap |
7 |
|
|
|
|
126 |
951 031 40
|
Seal |
7 |
|
|
|
|
127 |
946 218 40
|
Cap |
7 |
|
|
|
|
128 |
350 762 99
|
Washer |
11 |
|
|
|
|
129 |
307 646 99
|
Bolt |
11 |
|
|
|
|
130 |
969 835 40
|
Cap |
4 |
|
|
|
|
131 |
951 032 40
|
Seal |
4 |
|
|
|
|
132 |
946 224 40
|
Cap |
4 |
|
|
|
|
135 |
951 231 40
|
Gyrosensor |
1 |
|
|
|
|
136 |
978 192 40
|
Cable assy. |
1 |
|
|
|
|
137 |
950 125 40
|
Socket FEMALE |
11 |
|
|
|
|
138 |
0819105420
|
Female contact FEMALE |
284 |
|
|
|
|
139 |
621 699 40
|
Female contact 1-2 qmm FEMALE |
48 |
|
|
|
|
140 |
950 318 40
|
Panel lock washer |
20 |
|
|
|
|
141 |
0819150808
|
Nut |
20 |
|
|
|
|
142 |
950 898 40
|
Seal ring |
19 |
|
|
|
|
143 |
635 042 40
|
Wire end ferrule 1,5 |
53 |
|
|
|
|
144 |
940 852 40
|
Plug |
80 |
|
|
|
|
145 |
950 120 40
|
Socket FEMALE |
2 |
|
|
|
|
146 |
0819105440
|
Female contact FEMALE |
33 |
|
|
|
|
147 |
0819100770
|
Sealing plug |
17 |
|
|
|
|
148 |
056 071 40
|
Cable sleeve 2,5 |
33 |
|
|
|
|
151 |
950 117 40
|
Socket FEMALE |
1 |
|
|
|
|
152 |
941 426 40
|
Bushing contact FEMALE |
1 |
|
|
|
|
153 |
941 443 40
|
Plug |
2 |
|
|
|
|
154 |
269 078 40
|
Wire end ferrule 1,5 |
1 |
|
|
|
|
155 |
950 122 40
|
Socket FEMALE |
1 |
|
|
|
|
156 |
950 123 40
|
Socket MALE |
1 |
|
|
|
|
157 |
0819105320
|
Pin contact MALE |
32 |
|
|
|
|
158 |
621 698 40
|
Contact plug 1-2 qmm MALE |
5 |
|
|
|
|
159 |
950 126 40
|
Socket MALE |
1 |
|
|
|
|
160 |
950 140 40
|
Socket FEMALE |
1 |
|
|
|
|
161 |
950 146 40
|
Socket FEMALE |
2 |
|
|
|
|
162 |
950 143 40
|
Socket MALE |
1 |
|
|
|
|
163 |
0819110808
|
Nut |
1 |
|
|
|
|
164 |
0819110809
|
Lock washer |
1 |
|
|
|
|
165 |
950 897 40
|
Seal ring |
1 |
|
|
|
|
171 |
940 021 40
|
Relay |
1 |
|
|
|
|
172 |
323 910 40
|
Socket |
1 |
|
|
|
|
173 |
323 911 40
|
Spring |
1 |
|
|
