REAR SUSPENSION ASSM (EF8359) | AFE32-ED 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-ED 830E COLLAHUASI

1 2 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 26 20 21 22 23 24 25 8 27 4

#	Part Number	Partname	Quantity
1	ED0191	PISTON	1
2	WA0720	FLAT WASHER - 3/8" (HARDENED)	3
3	C0312	LOCKWASHER - 3/8"	2
4	C1602	CAPSCREW - 3/8" - 16NC X 1"	3
5	PB2194	CHARGING VALVE ASSM (1)/(2)	1
5	TD7179	CORE, VALVE	1
5	TR9993	CAP	1
5	TF1144	O-RING	1
5	WA0052	O-RING	1
6	VD5076	GASKET	1
7	TZ9083	PROTECTOR	1
8	TY8879	PLUG, VENT	2
9	VF4319	SCREW, BLEEDER	1
10	WA0106	SEAL, O-RING (2)	2
11	WA1281	RING, BACKUP (2)	2
12	WA2892	PLATE, WARNING	2
13	R1073	DRIVE SCREW - #6 X 3/16"	8
14	VJ3911	OIL, SUSPENSION - (5 GALLON CAN)	3
14	AK3761	ADDITIVE, OIL (5 GAL. CAN)	1
15	EC1973	HOUSING (3)	1
16	WA0362	FLAT WASHER - 3/4" (HARDENED)	12
17	VM4571	CAPSCREW - 3/4" - 10NC X 2 1/2"	12
18	ED0183	BEARING, BRONZE	1
19	H2981	BALL, STEEL - 3/4"	2
20	VN6801	CAPSCREW - 3/4" - 10NC X 3 1/2" (SOCKET HEAD)	24
21	ED8014	BEARING - BRONZE	1
22	EB8840	SENSOR, PRESSURE	1
22	TZ9715	ASSM, VALVE / LOAD WEIGHING	1
22	TD7179	CORE, VALVE	1
22	TZ8627	VALVE, BODY	1
22	TZ8628	ADAPTOR, PRESSURE SENSOR	1
22	07000051009	O-RING	1
23	PB7976	SEAL, ROD BUFFER - 12.00" (2)	1
24	PB8564	SEAL, ROD - DOUBLE LIP - 12.00" (2)	1
25	PB8867	SEAL, WIPER - 12.00" (2)	1
26	VZ4269	GUARD, VALVE	1
27	TZ9715	ASSM, VALVE / LOAD WEIGHING	1
27	WA3417	DECAL, WARNING HYDRAIR (SPANISH)	1
NS\|39	RK1887	NOTE: (1) INCLD IN RK1887 CHARGING VALVE REPAIR KIT.	65535
NS\|40	AK7161	(2) INCLD IN AK7161 REAR SUSP SEAL KIT.	65535
NS\|41	EC5318	(3) SVCD AS EC5318 HOUSING.	65535
NS\|42		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY)	65535
