AFE32-FA 830E COLLAHUASI

Komatsu parts book diagram for AFE32-FA 830E COLLAHUASI: STEERING COLUMN ASSEMBLY - 5 (PB9380)

? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	VE4310	BOLT - 3/8" - 24NF	4
	?	VE4311	LOCKWASHER	4
	?	VE4309	BRACKET, MOUNTING	1
	?	VE4299	COVER	1
	?	BF2070	COVER, KIT	1
	?		COVER, UPPER (1)	1
	?		COVER, LOWER (1)	1
	?		HOUSING & SHAFT ASSEMBLY (1)	1
	?	BF2074	HORN BRUSH KIT	1
	?		RING, WEDGE (1)	1
	?		HOUSING & PLATE ASSEMBLY (1)	1
	?		NUT (1)	1
	?		NUT (1)	1
	?		LOCKWASHER	2
	?	BF2068	TILT BOLT KIT	1
	?		BOLT, TILT (1)	2
	?		FLAT WASHER (1)	2
	?		O-RING (1)	2
	?	BF2071	TILT STOP KIT	1
	?		TILT STOP (1)	2
	?		SCREW (1)	2
	?		WASHER (1)	2
	?	BF2072	TILT LEVER KIT	1
	?		ROD (1)	65535
	?		KNOB - LOCKING ROD (1)	65535
	?		PIN - SPRING (1)	65535
	?	BF2073	ROD & PAWL KIT	1
	?		ROD & PAWL ASSEMBLY (1)	1
	?		PIN - SPRING (1)	1
	?		SPRING (1)	2
	?		KNOB - LOCKING ROD (1)	1
	?		RING, RETAINING (1)	1
	?		PLATE, ANTI-ROTATION (1)	1
	?		PAWL (1)	1
	?	PB2069	CAP HIDER KIT	1
	?		COVER ASSEMBLY (1)	1
	?		NUT (1)	1
	?		LOCKWASHER (1)	2
	?		NUT (1)	1
	?	PB7022	SWITCH, TURN SIGNAL & DIMMER	1
	?	VE4308	ACTUATOR, TELESCOPE (2)	1
	?		NOTE: (1) NOT SVCD SEPARATELY.	65535
	?		(2) LOCATED AROUND HORN BUTTON	65535

Komatsu AFE32-FA 830E COLLAHUASI parts catalog PDF

STEERING COLUMN ASSEMBLY - 5 (PB9380) (41193) in AFE32-FA 830E COLLAHUASI. Diagram image and parts list.
