SPINDLE, HUB & BRAKE INSTALLATION | AFE32-EZ 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-EZ 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EB1716	HOUSING, FRONT WHEEL	1
?	PB7362	DISC BRAKE ASSEMBLY (SEE INDEX)	3
?	YA0447	SUPPORT, BRAKE	1
?	WA4682	CAPSCREW - 1" - 14NF X 14 1/2"	18
?	WA0364	FLATWASHER - 1"	30
?	VN7703	NUT - 1" - 14NF	18
?	VM8258	CAPSCREW - 1" - 8NC X 3 3/4"	18
?	PB7003	CUP, BEARING (1)	1
?	PB7002	CONE, BEARING (1)	1
?	YA1078	SPINDLE	1
?	EB1715	SPACER	1
?	PB5756	SEAL ASSEMBLY (1)	1
?	VN9143	CAPSCREW - 1 1/4" - 7NC X 4"	64
?	TY2149	FLATWASHER (HARDENED)	64
?	TX4848	DISC	1
?	TY1633	STUD - 1" - 14UNS X 7 1/4"	35
?	PB6218	CUP, BEARING (1)	1
?	PB6217	CONE, BEARING (1)	1
?	H6881	PLUG, PIPE	1
?	TH6916	VALVE, CHECK (1)	1
?	TY2148	FLATWASHER (HARDENED)	6
?	TY2134	BEARING, RETAINER	1
?	WA4795	SEAL, O-RING (1)	1
?	C1616	CAPSCREW - 1/2" - 13NC X 2"	8
?	C1540	LOCKWASHER - 1/2"	8
?	EC3702	COVER	1
?	TY2135	SHIM - .002 (1)	11
?	TY2136	SHIM - .014 (1)	2
?	TY2137	SHIM - .031 (1)	6
?	WA0362	FLATWASHER - 3/4"	8
?	TX0807	ANGLE	1
?	TH7593	FITTING, ELBOW - 90 DEG	1
?	TX0805	TUBE	1
?	VY8331	CLAMP	1
?	DC7524	CAPSCREW - 3/8" - 16NC X 7/8"	1
?	WA0720	FLAT WASHER - 3/8"	1
?	C0312	LOCKWASHER - 3/8"	1
?	C1521	NUT - 3/8" - 16NC	1
?	TF5190	FITTING, TUBE CONNECTOR	3
?	TX0808	BLEEDER, REMOTE	2
?	R2028	PLUG, PIPE	1
?	PB7509	SCREW, BLEEDER	2
?		(NOT USED THIS APPLICATION)	65535
?	TR6102	SCREW, BLEEDER (2)	2
?	TR6102	SCREW, BLEEDER (2)	2
?	WB0576	FITTING, STRAIGHT ADAPTOR	2
?	TZ7732	TUBE - L.H.	1
?	TZ7733	TUBE - R.H.	1
?	PB7454	GAUGE, SIGHT	1
?	SD5211	BUSHING, PIPE	1
?	AK7471	NOTE: (1) INCLUDED IN AK7471 BEARING KIT.	65535
?		(2) PART OF BRAKE ASSEMBLY.	65535
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY)	65535
