FRONT SUSPENSION & MOUNTING | AFE32-EZ 830E COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE32-EZ 830E COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EF8357	FRONT SUSPENSION ASSEMBLY - 14.00"	1
?	WA2892	PLATE, WARNING	2
?	R1073	DRIVE SCREW - #6 X 3/16"	8
?	VN9077	CAPSCREW - 3/4" - 10NC X 2 1/4"	24
?	WA0362	FLATWASHER - 3/4"	48
?	EC4593	CAP, SUSPENSION	1
?	TY8879	PLUG, VENT	1
?	TM9278	PROTECTOR	1
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	2
?	C0312	LOCKWASHER - 3/8"	2
?	PB2194	CHARGING VALVE ASSEMBLY (1)/(2)	1
?	TD7179	CORE, VALVE	1
?	TR9993	CAP	1
?	TF1144	O-RING	1
?	WA0052	O-RING	1
?	VD5076	GASKET	1
?	WA0106	SEAL, O-RING (1)	4
?	WA1281	RING, BACKUP (1)	4
?	VN9105	CAPSCREW - 7/8" - 9NC X 3"	12
?	WA0363	FLATWASHER - 7/8"	12
?	TZ0302	BEARING, UPPER	1
?	TY8125	WASHER, SNUBBER	1
?	H2981	BALL, STEEL - 3/4"	2
?	VW4451	NUT, WHEEL	1
?	VC2629	PIN	1
?	EF8395	PISTON	1
?	EF8393	BEARING	1
?	VN9130	CAPSCREW - 3/4" - 10NC X 3 3/4"	24
?	VM0314	PLUG, O-RING	1
?	VJ3911	OIL, SUSPENSION - (5 GALLON CAN)	5
?	TY5376	HOUSING	1
?	PB7978	SEAL, ROD BUFFER - 14" (1)	1
?	PB9581	SEAL, ROD DOUBLE LIP - 14" (1)	1
?	PB9580	SEAL, WIPER - 14" (1)	1
?	TZ0316	PLATE	1
?	TZ8637	PLUG - SENSOR	1
?	WA0404	NUT - 1 1/2" - 6NC	10
?	TX9708	KEY, SHEAR	1
?	EB2082	CAPSCREW - 1 1/2" - 6NC X 12 1/2"	8
?	TX9710	SPACER	4
?	TY9252	BOOT	1
?	TY9253	WIRE, BOOT	1
?	WA2955	CLAMP, HOSE	2
?	VN9182	CAPSCREW - 1 1/2" - 6NC X 6"	6
?	WA0368	FLATWASHER - 1 1/2"	24
?	TY2149	FLATWASHER	12
?	TY2228	PLATE, RETAINING	1
?	WA4817	CAPSCREW - 1 1/4" - 12NF X 5" (12 POINT)	12
?	AK7160	NOTE: (1) INCLUDED IN AK7160 SEAL KIT.	65535
?	RK1887	(2) INCLUDED IN RK1887 CHARGING VALVE	65535
?		REPAIR KIT.	65535
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY)	65535
