BATTERY CHARGING ALTERNATOR (EF2654) | AFE47-AD 730E SISHEN (A30095 & A30098)

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-AD 730E SISHEN (A30095 & A30098)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	BF3715	LOCKNUT (1)	1
?	BF1997	FLAT WASHER (1)	1
?	EF3527	PULLEY	1
?	BF1966	BUSHING, PULLEY	1
?	BF1989	RING, RETAINER (1)	1
?	BF1968	BEARING, FRONT	1
?	BF1988	RING, RETAINER (1)	1
?	BF1990	MACHINE SCREW - #8 - 32NC X 3/8" (1)	15
?	BF1970	PLATE, COVER	1
?	BF3712	HOUSING, FRONT	1
?	BF2002	NUT - (SPECIAL)	18
?	BF1969	COVER, CONTROL UNIT	1
?	BF1972	TERMINAL, OUTPUT	1
?	BF1971	CONTROL UNIT	1
?	BF3716	CAPSCREW - 5/16" - 18NC X 3/4"	1
?	BF1995	LOCKWASHER - 5/16" (1)	1
?	BF1996	FLAT WASHER (1)	1
?	BF3717	LOCKWASHER (1)	1
?	BF3718	CAPSCREW - 1/2" - 13NC X 1" (1)	1
?	BF3720	KEY WOODRUFF (1)	1
?	BF1973	SHAFT/CORE/ROTOR ASSEMBLY	1
?	BF1974	ROTOR ASSEMBLY	2
?	BF1975	SHAFT/CORE ASSEMBLY	1
?	BF3713	RING, RETAINING	2
?	BF1992	LOCKWASHER (1)	2
?	BF1991	CAPSCREW - 3/8" - 16NC X 5/8" (1)	2
?	BF3719	CAPSCREW - #10 - 32NF X 1/2" (1)	12
?	BF3721	NUT - #8 - 32NC (1)	9
?	BF1976	SHELL/STATOR/FIELD ASSEMBLY	1
?	BF1977	STATOR, FRONT	1
?	BF1980	STUD	9
?		SHELL (2)	1
?	BF1981	BUSHING, TENSION	1
?	BF1978	COIL	1
?	BF1979	STATOR, REAR	1
?	BF3722	MACHINE SCREW - #6 - 32NF X 3/8" (1)	18
?	BF3723	NUT - #8 (1)	9
?	BF1982	HOUSING, END	1
?	BF1983	BEARING, REAR	1
?	BF3724	SCREW, LOCK - #10 - 32NC X 5/8" (1)	2
?	BF1962	REGULATOR	1
?	BF3714	O-RING	1
?	BF1985	FAN	1
?	BF2003	FLAT WASHER (HARDENED) (1)	1
?	BF2004	LOCKNUT - 1/4" - 20NF (1)	1
?	BF1961	GUARD, FAN	1
?	BF3725	MACHINE SCREW - #10 - 32NF X 7/8" (1)	3
?	BF1986	NOTE: (1) NOT SERVICED SEPARATELY - SUPPLIED	65535
?		ONLY IN KIT BF1986.	65535
?		(2) NOT SOLD SEPARATELY.	65535
