SPINDLE, HUB & BRAKE INSTALLATION | AFE47-AD 730E SISHEN (A30095 & A30098)

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-AD 730E SISHEN (A30095 & A30098)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EH2604	SPINDLE HUB & BRAKE ASSEMBLY	1
?	VM0315	PLUG, O-RING	1
?	C1540	LOCKWASHER - 1/2"	16
?	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	16
?	WA4795	SEAL, O-RING (1)	1
?	PC0005	BEARING CUP, SINGLE TAPERED ROLLER (1)	1
?	PB9999	BEARING CONE, SINGLE TAPERED ROLLER (1)	1
?	PB7454	GAGE, SIGHT	1
?	SD5211	BUSHING	1
?	TY2134	RETAINER, BEARING	1
?	TH6916	VALVE, CHECK	1
?	H6881	PLUG, PIPE	1
?	TY2148	FLAT WASHER (HARDENED)	6
?	VM8258	CAPSCREW - 1" - 8NC X 3 3/4"	18
?	TY2136	SHIM - .014 (1)	2
?	TY2137	SHIM - .031 (1)	3
?	TY2135	SHIM - .002 (1)	5
?	EC3702	COVER	1
?	EB8390	HUB - 57"	1
?	TY1633	STUD - 1" - 14UNS X 7 1/4"	35
?	PB7362	DISC BRAKE ASSEMBLY (SEE INDEX)	3
?	EC3706	ADAPTOR, BRAKE	1
?	WA4682	CAPSCREW	18
?	VN7703	NUT	18
?	WA0364	FLAT WASHER - 1"	30
?	TX0808	BLEEDER, REMOTE	1
?	562-22-32290	PIN (1)	2
?	TF5190	FITTING, TUBE	1
?	WA0362	FLAT WASHER - 3/8" (HARDENED)	4
?	PC0003	BEARING CUP, SINGLE TAPERED ROLLER (1)	1
?	PB9997	BEARING CONE, SINGLE TAPERED ROLLER (1)	1
?	EC2056	SPACER, BEARING	1
?	EH2300	SPINDLE	1
?	WA5466	SEAL, O-RING (1)	1
?	PB5756	SEAL ASSEMBLY (1)	1
?	EC2057	CARRIER, SEAL	1
?	WA4818	CAPSCREW - 1 1/4" 7 7NC X 4"	30
?	TY2149	FLAT WASHER, HARDENED	60
?	WA4510	CAPSCREW	30
?	TY6050	DISC, BRAKE	1
?	TX0807	ANGLE	1
?	TH7593	FITTING, ELBOW	1
?	TX0805	TUBE, HYDRAULIC	1
?	VY8331	CLAMP	1
?	DC7524	CAPSCREW - 3/8" - 16NC X 7/8"	1
?	WA0720	FLAT WASHER - 3/8" (HARDENED)	1
?	C0312	LOCKWASHER - 3/8"	1
?	C1521	NUT - 3/8" - 16NC	1
?	AK4176	NOTE: (1) INCLUDED IN AK4176 SPINDLE MAINTENANCE KIT.	65535
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY)	65535
