FRONT SUSPENSION & MOUNTING - 1 | AFE47-AD 730E SISHEN (A30095 & A30098)

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-AD 730E SISHEN (A30095 & A30098)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EF8365	FRONT SUSPENSION ASSEMBLY - 13"	1
?	WA2892	PLATE, WARNING	2
?	R1073	DRIVE SCREW - #6 X 3/16"	8
?	VN9087	CAPSCREW - 5/8" - 11NC X 2 1/2"	24
?	WA0361	FLAT WASHER - 5/8" (HARDENED)	48
?	EF5477	CAP, SUSPENSION	1
?	TY8879	PLUG, VENT	1
?	TM9278	PROTECTOR	1
?	C1602	CAPSCREW - 3/8" - 16NC X 1"	2
?	C0312	LOCKWASHER - 3/8"	2
?	PB2194	CHARGING VALVE ASSEMBLY (1)/(2)	1
?	TD7179	CORE, VALVE	1
?	TR9993	CAP	1
?	TF1144	O-RING	1
?	WA0052	O-RING	1
?	VD5076	GASKET (1)/(2)	1
?	WA0105	SEAL, O-RING (1)	4
?	WA1280	RING, BACKUP (1)	4
?	VN9105	CAPSCREW - 7/8" - 9NC X 3"	12
?	WA0363	FLAT WASHER - 7/8" (HARDENED)	12
?	TZ7658	BEARING, BRONZE (UPPER)	1
?	TY8125	WASHER, SNUBBER	1
?	H2981	BALL, STEEL - 3/4"	2
?	VW4451	NUT, WHEEL	1
?	VC2629	PIN	1
?	EF7977	PISTON	1
?	EF8396	BEARING, BRONZE (LOWER)	1
?	VN9129	CAPSCREW - 5/8" - 11NC X 3 3/4"	24
?	VM0314	PLUG, O-RING	1
?	VJ3911	OIL, SUSPENSION - STANDARD (5 GAL CAN)	4
?	AK3761	ADDITIVE, OIL (5 GAL CAN)	1
?	TZ9718	HOUSING	1
?	PB7977	SEAL, ROD BUFFER - 13" (1)	1
?	PB9790	SEAL, ROD DOUBLE LIP - 13" (1)	1
?	PB9789	SEAL, WIPER - 13" (1)	1
?	TZ1626	PLATE	1
?	TZ8637	PLUG, SENSOR	1
?	WA0404	NUT - 1 1/2" - 6NC	10
?	TZ1637	KEY, SHEAR	1
?	EB2080	CAPSCREW - 1 1/2" - 6NC X 10 3/4"	8
?	TX9710	SPACER	4
?	TZ4354	BOOT	1
?	TZ4355	WIRE, BOOT	1
?	WA1754	CLAMP, HOSE	2
?	VN9182	CAPSCREW - 1 1/2" - 6NC X 6"	6
?	WA0368	FLAT WASHER - 1 1/2"	24
?	TY2149	FLAT WASHER (HARDENED)	8
?	TZ1439	PLATE, RETAINING	1
?	WA4817	CAPSCREW - 1 1/4" - 12NF X 5" (12 POINT)	8
?	AK3869	NOTE: (1) INCLUDED IN AK3869 SUSPENSION KIT.	65535
?	RK1887	(2) INCLUDED IN CHARGING VALVE KIT RK1887.	65535
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY)	65535
