AFE47-FQ 730E S/N A30546 - A30549 ROSSING URANIUM

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	PB4255	MODULE, SUPPRESSION	2
?	TF6376	MACHINE SCREW - #10 - 24NC X 1 1/4"	6
?	DC3101	LOCKWASHER - #10	6
?	VC5344	FLAT WASHER - #10	6
?	DF0017	NUT - #10 - 24NC	6
?	TZ7539	PLATE, NAME - GB4	1
?	TZ7524	PLATE, NAME - VMM1	1
?	TZ7525	PLATE, NAME - VMM2	1
?	VE6118	PANEL (SEE INDEX)	2	64067
?	MM0469	LOCKWASHER - M6	32
?	MM0459	FLAT WASHER - M6	32
?	MM0176	NUT - M6 X 1.00	32
?	TZ7530	PLATE, NAME - 1SOA5	1
?	EB7405	PLATE, NAME - 1S0A8	1
?	TZ7529	PLATE, NAME - 1SOA4	1
?	TZ7532	PLATE, NAME - 1SOA7	1
?	PB4252	PANEL, IS0 AMP (SEE INDEX)	6	64066
?	TZ7531	PLATE, NAME - 1SOA6	1
?	TZ7528	PLATE, NAME - 1SOA3	1
?	EG2444	ANGLE BRACKET, INSULATING	1

Komatsu AFE47-FQ 730E S/N A30546 - A30549 ROSSING URANIUM parts catalog PDF

CONTROL CABINET ASSEMBLY - L.H. SIDE (55205) in AFE47-FQ 730E S/N A30546 - A30549 ROSSING URANIUM. Diagram image and parts list.
