PANEL - MFSE (PB8837) | AFE47-FH 730E S/N A30524 NITTETSU

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
1	PB8837	STATIC EXCITER PANEL, MOTOR FIELD	1
2	VE4900	PANEL BOX	1
3	VE4901	HEAT SINK	2
4	TR1306	CAPSCREW - 1/4" - 20NC X 1"	12
5	VE7202	FLAT WASHER - 1/4"	-1
6	DC3584	LOCKWASHER - 1/4"	-1
7	VE4902	NUT	-1
8	VE4903	BUS BAR	2
9	VE0300	BAR, BUS	2
10	SH7597	CAPSCREW - 1/4" - 20NC X 1/2"	4
11	C5746	CAPSCREW - 1/4" - 20NC X 3/4"	12
12	VE0301	BAR, BUS	2
13	VE0302	BAR, BUS	2
14	VE0297	BAR, BUS	2
15	VS7514	BOARD, TERMINAL	1
16	VE4904	PLATE, INDICATOR	1
17	VE4905	MACHINE SCREW - #10 - 32NF X 1 1/4"	6
18	VS6662	FLAT WASHER - #10	-1
19	DC3101	LOCKWASHER - #10	-1
20	SF2755	NUT - #10 - 32NF	8
21	VE5098	SUPPORT	2
22	VE4382	RECEPTACLE, LATCHING	2
23	VE4383	MACHINE SCREW - #4 - 40NF X 1/2"	4
24	VE4907	FLAT WASHER	4
25	VE4908	LOCKWASHER	4
26	VE4909	NUT	4
27	VE0039	DIODE	2
28	VE4910	PANEL ASSEMBLY (SEE INDEX)	1	64074
29	VE4911	HINGE	1
30	VE4912	MACHINE SCREW - #8 - 5/8"	5
31	VE4913	MACHINE SCREW - #8 - 3/4"	5
32	VE0040	RECTIFIER	2
33	VE4914	CLAMP	4
34	VE4389	SHIELD, INSULATION	1
35	VE4915	MACHINE SCREW - #8 - 18NC X 1/2"	9
36	VP9525	PIN, SPRING DOWEL	4
37	VE4916	MACHINE SCREW - #10 - 32NF X 1/2"	6
38	VE4917	CLAMP, CABLE	1
39	VE4918	CLAMP, CABLE	1
40	VE4921	MACHINE SCREW - #10 - 32NF X 1"	2
41	VE4604	FLAT WASHER	-1
42	VE6320	CAPSCREW - 1/4" - 20NC X 1 1/8"	4
43	BF0932	SENSOR, THERMISTOR - 100,000 OHM	1
NS\|44		NOTE: NS = NOT SHOWN	-1
NS\|45	VE6321	CLAMP, CABLE	1
NS\|46	VE6322	CLAMP, CABLE	1
NS\|47	VE6323	CLAMP, CABLE	2
