AFE47-V 730E S/N 32795 & 32797 ISCOR GROOTEGELUK

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	BF3149	O-RING	1
?	BF2816	BODY, OUTLET	1
?	VJ9192	SEAL, OIL	2
?	BF3150	RING, RETAINING	2
?	BF3151	O-RING	1
?	BF3158	FLANGE	1
?	BF3159	SCREW	4
?	BF2817	SHAFT	1
?	C9809	BEARING, BALL	1
?	SP1068	RING, RETAINING	1
?	VS0616	RING, LOCK	1
?	BF2820	CARTRIDGE KIT ASSEMBLY	1
?	BF3155	RING, BACK-UP	2
?	BF3152	RING, BACK-UP	2
?	BF3153	O-RING	2
?	BF3152	RING, BACK-UP	2
?	BF3154	O-RING	2
?	BF3155	RING, BACK-UP	2
?	BF3881	HOUSING	1
?	BF3870	CARTRIDGE KIT ASSEMBLY	1
?	BF3871	RING, BACK-UP	2
?	BF3872	O-RING	2
?	BF3874	RING, BACK-UP	2
?	BF3875	CARRIER, BEARING	1
?	BF3876	RING, RETAINER	1
?	BF3877	O-RING	1
?	BF3878	SCREW	1
?	BF3879	COVER	1
?	BF3880	SCREW	4

Komatsu AFE47-V 730E S/N 32795 & 32797 ISCOR GROOTEGELUK parts catalog PDF

DOUBLE VANE/CARTRIDGE PUMP (PC0094) (55319) in AFE47-V 730E S/N 32795 & 32797 ISCOR GROOTEGELUK. Diagram image and parts list.
