AFE48-CK 930E-2 S/N A30225 JACOB'S RANCH

Komatsu parts book diagram for AFE48-CK 930E-2 S/N A30225 JACOB'S RANCH: REAR WHEEL COOLING (EXHAUST)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	EG9757	TUBE	1
	?	TR6008	FLAT WASHER - 1/2"	6
	?	VN9743	NUT, WING - 1/2" - 13NC	4
	?	EF9558	TUBE	1
	?	C0312	LOCKWASHER - 3/8"	24
	?	C1601	CAPSCREW - 3/8" - 16NC X 3/4"	24
	?	EF9598	COVER	2
	?	EF9590	WRAPPER, INNER	1
	?	HA0750	HOSE	1
	?	WB0252	FITTING, ELBOW - 90 DEG	1
	?	HA7165	HOSE	1
	?	WB0556	FITTING, TEE	1
	?	WB0374	FITTING, ELBOW - 90 DEG	1
	?	WB0505	FITTING, ELBOW - 90 DEG	1
	?	HA5579	HOSE	1

Komatsu AFE48-CK 930E-2 S/N A30225 JACOB'S RANCH parts catalog PDF

REAR WHEEL COOLING (EXHAUST) (60074) in AFE48-CK 930E-2 S/N A30225 JACOB'S RANCH. Diagram image and parts list.
