AFE50-AG 830E S/N A30641 ANTELOPE COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EH7374	HARNESS, PLM	1
?	VZ2691	LOCKNUT, CONDULET	1
?	PB9813	TRANSFORMER, ISOLATION	1
?	WA2550	SETSCREW - #10 - 24NC X 3/4"	2
?	DL4172	SLEEVE, INSULATING	4
?	SF9896	KNIFE, DISCONNECT	4
?	SM1947	RELAY BOARD ASSEMBLY - RB2 (SEE FIG 60475)	1	60475
?	MM0459	FLAT WASHER - M6	4
?	MM0469	LOCKWASHER - M6	4
?	MM0176	NUT - M6 X 1.00	4
?	EB2848	LIGHT ASSEMBLY - RED (SEE FIG 41372)	2	41372
?	EB2847	LIGHT ASSEMBLY - AMBER (SEE FIG 41372)	2	41372
?	EB2846	LIGHT ASSEMBLY - GREEN (SEE FIG 41372)	2	41372
?	HD6007	SCREW, MACHINE - #10 - 24NC X 3/4"	18
?	VC5344	FLAT WASHER - #10	18
?	DC3101	LOCKWASHER - #10	18
?	DF0017	NUT - #10 - 24NC	18
?	EH0728	HARNESS, RIGHT FRAME RAIL	1
?	WA4887	CLAMP	4
?	VG7146	CAPSCREW - 1/2" - 13NC X 3/4"	8
?	TR6008	FLAT WASHER - 1/2"	8
?	TR5445	LOCKWASHER - 1/2"	8
?	EF8679	LOAD WEIGH VALVE ASSEMBLY	4
?	TZ8627	BODY, VALVE	4
?	TD7179	CORE, VALVE	4
?	EF8677	ADAPTOR, TRANSDUCER	4
?	07000-51009	O-RING	4
?	EF8669	TRANSDUCER	4
?	TZ8636	COVER	4
?		NOTE: NS = NOT SHOWN	-1
?	EH7476	HARNESS, FRONT SUSPENSIONS	1
?		NOTE: SEE OVERHEAD DASH PAGE FOR PAYLOAD METER MODULE.	-1
