AFE48-V 930E S/N 32816 & 32837 PHELPS-DODGE MORENCI

6 1 4 5 2 3 7 8 9 57 10 11 14 13 12 18 19 20 21 22 23 24 25 15 16 17 26 27 28 29 30 31 32 33 34 35 36 37 38 44 45 46 47 51 52 53 41 42 43 39 40 48 49 55 56 50 54

#	Part Number	Partname	Quantity
1	GE0243	SET, LABEL - (CT-R1)	1
2	GE0244	SET, LABEL - (A3PV-GFC0)	1
3	GE0245	SET, LABEL - (AXFU11-RTNBUS)	1
4	GE0209	SET, LABEL - (DCN1BUS-RDBUSAC3)	1
5	BF3909	SET, LABEL - (REST MODE - TEST MODE)	1
6	GE0248	SET, LABEL - (INVERTER #1 - INVERTER #2)	1
7	GE0249	LABEL, CHART RECORDER	1
8	GE0250	SET, LABEL - (NORMAL CUTOUT - ON - OFF)	1
9	BF3910	LABEL, G.F.C.	1
10	GE0252	LABEL, ECT	1
11	BF3911	PIN, COTTER	8
12	VJ8249	MACHINE SCREW - #8 - 36 X 3/4" (FILISTER HEAD)	4
13	GE0255	MACHINE SCREW - #10 - 32 X 7/16" (HEX HEAD)	2
14	VJ9161	MACHINE SCREW - #10 - 32 X 1/2" (HEX HEAD)	1
15	VJ6586	MACHINE SCREW - #10 - 32 X 3/4" (HEX HEAD)	8
16	VE4921	MACHINE SCREW - #10 - 32 X 1" (HEX HEAD)	6
17	GE0256	MACHINE SCREW - #10 - 32 X 1 7/8" (HEX HEAD)	4
18	C5746	CAPSCREW - 1/4" - 20NC X 3/4"	12
19	VE5882	CAPSCREW - 1/4" - 20NC X 7/8"	-1
20	BF0699	CAPSCREW - 5/16" - 18NC X 3/4"	12
21	VE4349	CAPSCREW - 5/16" - 18NC X 7/8"	4
22	BF3889	CAPSCREW - 5/16" - 18NC X 1"	4
23	VE4641	CAPSCREW - 3/8" - 16NC X 1 1/4"	-1
24	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2"	10
25	GE0257	CAPSCREW - 3/8" - 16NC X 1 7/8"	10
26	GE0256	CAPSCREW - 1/2" - 13NC X 1 3/8"	5
27	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	12
28	VE4999	CAPSCREW - 1/2" - 13NC X 2"	3
29	GE0259	CAPSCREW - 1/2" - 13NC X 2 1/8"	12
30	C1620	CAPSCREW - 1/2" - 13NC X 3"	4
31	VE6232	CAPSCREW - 1/2" - 13NC X 3 1/4"	-1
32	VE4992	CAPSCREW - 5/8" - 11NC X 1 3/4"	2
33	VE4604	FLAT WASHER - #8 (NARROW)	4
34	VS6662	FLAT WASHER - #10 (NARROW)	3
35	VE4655	FLAT WASHER - #10	-1
36	VE7202	FLAT WASHER - 1/4" (NARROW)	-1
37	BF3890	FLAT WASHER - 5/16" (NARROW) STAINLESS STEEL	-1
38	VE4648	FLAT WASHER - 5/16"	-1
39	VE4516	FLAT WASHER - 3/8" (NARROW)	-1
40	VE4515	FLAT WASHER - 3/8"	-1
41	VE4490	FLAT WASHER - 1/2" (NARROW)	-1
42	VE4519	FLAT WASHER - 1/2" (NARROW)	-1
43	VE5169	FLAT WASHER - 5/8"	-1
44	VE4606	LOCKWASHER - #8	4
45	VC1390	LOCKWASHER - #10	-1
46	DC3584	LOCKWASHER - 1/4"	-1
47	BF3891	LOCKWASHER - 5/16" STAINLESS STEEL	-1
48	VE4687	LOCKWASHER - 3/8"	-1
49	VE4699	LOCKWASHER - 1/2"	-1
50	VE5171	LOCKWASHER - 5/8"	-1
51	SF2755	NUT - #10 - 32	-1
52	VE4481	NUT - 1/4" - 20NC SELF LOCKING	-1
53	VE5013	NUT - 5/16" - 18NC	-1
54	TC1233	NUT - 3/8" - 16NC	-1
55	VE4698	NUT - 1/2" - 13NC	-1
56	GE0045	NUT - 5/8" - 11NC	-1
57	GE0209	SET, LABEL (DCN1BUS-RDBUSAC3)	1
NS\|58		NOTE: NS = NOT SHOWN	-1
NS\|59	VE8185	CEMENT	-1
NS\|60	VE7272	SEALANT (TRANSLUSCENT)	-1
NS\|61	GE0213	SEALING COMPOUND	-1

Komatsu AFE48-V 930E S/N 32816 & 32837 PHELPS-DODGE MORENCI parts catalog PDF

HARDWARE, DECAL & MISCELLANEOUS (64031) in AFE48-V 930E S/N 32816 & 32837 PHELPS-DODGE MORENCI. Diagram image and parts list.
