1 |
|
BOX, BATTERY (SEE FIG 41708) |
1 |
|
41708 |
|
|
2 |
|
BOX, BATTERY DISCONNECT SWITCH (SEE FIG 41618) |
1 |
|
41618 |
|
|
3 |
VN5153
|
WIRE, GROUND (GRID ASSEMBLY TO DECK) |
2 |
|
|
|
|
4 |
VH9969
|
STUD, WELD - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
5 |
SP6153
|
LOCKWASHER - 3/8" (INT-EXT TOOTH) |
4 |
|
|
|
|
6 |
C0312
|
LOCKWASHER - 3/8" |
15 |
|
|
|
|
7 |
TC1233
|
NUT - 3/8" - 16NC |
11 |
|
|
|
|
8 |
AK7504
|
LIGHT, SERVICE (SEE FIG 40869) |
2 |
|
40869 |
|
|
9 |
EJ5651
|
HARNESS, R.H. UPRIGHT |
1 |
|
|
|
|
10 |
TG2568
|
CLAMP - 7/8" I.D. |
18 |
|
|
|
|
11 |
MM0471
|
LOCKWASHER - M10 |
8 |
|
|
|
|
12 |
MM0178
|
NUT - M10 X 1.50 |
8 |
|
|
|
|
13 |
EJ3891
|
CLAMP ASSEMBLY |
25 |
|
|
|
|
14 |
EJ3892
|
ROD, THREADED |
25 |
|
|
|
|
15 |
MM0459
|
FLAT WASHER - M6 |
25 |
|
|
|
|
16 |
PB8735
|
SWITCH, MOMENTARY ON/ON (ENGINE SHUTDOWN) |
1 |
|
|
|
|
16 |
TZ6931
|
PLATE, TITLE |
1 |
|
|
|
|
17 |
TZ0880
|
COVER, SWITCH |
1 |
|
|
|
|
18 |
VZ1243
|
GRIP, CORD |
2 |
|
|
|
|
19 |
PB4043
|
GASKET, RUBBER |
2 |
|
|
|
|
20 |
PB9075
|
CONDULET, SINGLE GANG |
2 |
|
|
|
|
21 |
HE2467
|
SCREW, MACHINE - #6 - 32NC X 1/2" |
8 |
|
|
|
|
22 |
TR4065
|
CAPSCREW - 1/4" - 20NC X 1/2" |
4 |
|
|
|
|
23 |
DC3584
|
LOCKWASHER - 1/4" |
4 |
|
|
|
|
24 |
TD1549
|
NUT - 1/4" - 20NC |
4 |
|
|
|
|
25 |
VA2828
|
SWITCH, FLUSH HEAD |
1 |
|
|
|
|
26 |
VA2826
|
COVER, SINGLE GANG |
1 |
|
|
|
|
27 |
MM0176
|
NUT - M6 X 1.00 |
25 |
|
|
|
|
28 |
EJ8393
|
BRACKET, MOUNTING |
1 |
|
|
|
|
29 |
TR1376
|
CAPSCREW - 1/2" - 13NC X 1 1/4" |
2 |
|
|
|
|
30 |
DF3500
|
NUT - 1/2" - 13NC |
2 |
|
|
|
|
31 |
EJ5576
|
CLAMP ASSEMBLY |
21 |
|
|
|
|
32 |
EJ5654
|
HARNESS, R.H. DECK JUMPER |
1 |
|
|
|
|
33 |
AK8456
|
LIGHT, FRONT TURN & CLEARANCE (SEE FIG 41107) |
1 |
|
41107 |
|
|
34 |
C1601
|
CAPSCREW - 3/8" - 16NC X 3/4" |
4 |
|
|
|
|
35 |
DF3042
|
FLAT WASHER - 3/8" |
4 |
|
|
|
|
36 |
TY7470
|
PLATE, MOUNTING |
1 |
|
|
|
|
37 |
DC5004
|
SCREW, MACHINE - #12 - 24NC X 1/2" |
3 |
|
|
|
|
38 |
VD2047
|
LOCKWASHER - #12 |
3 |
|
|
|
|
39 |
TR8580
|
NUT - #12 - 24NC |
3 |
|
|
|
|
40 |
EJ5657
|
HARNESS, R.H. FRAME RAIL |
1 |
|
|
|
|
41 |
EB5963
|
JUNCTION BOX ASSEMBLY - R.H. |
1 |
|
|
|
|
42 |
EB5966
|
BOX |
1 |
|
|
|
|
43 |
WA3367
|
NUT ASSEMBLY |
24 |
|
|
|
|
44 |
VS8479
|
BOARD, TERMINAL |
2 |
|
|
|
|
45 |
VF2231
|
SCREW, MACHINE - #10 - 24NC X 3/8" |
4 |
|
|
|
|
46 |
DC3101
|
LOCKWASHER - #10 - 24NC X 3/8" |
4 |
|
|
|
|
47 |
SR8325
|
SWITCH, TOGGLE |
1 |
|
|
|
|
48 |
PB3324
|
BOOT, SWITCH |
1 |
|
|
|
|
49 |
WB2112
|
STRIP, CIRCUIT I.D. |
1 |
|
|
|
|
50 |
WB2886
|
STRIP, CIRCUIT I.D. |
1 |
|
|
|
|
51 |
VM2951
|
SCREW, SELF TAPPING - #6 - 32NC X 5/16" |
2 |
|
|
|
|
52 |
TD1548
|
CAPSCREW - 1/4" - 20NC X 5/8" |
4 |
|
|
|
|
53 |
SP8417
|
FLAT WASHER - 1/4" |
4 |
|
|
|
|
54 |
DC3584
|
LOCKWASHER - 1/4" |
4 |
|
|
|
|
55 |
EK7154
|
CLAMP ASSEMBLY |
13 |
|
|
