AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	PB8205	LIGHT, BRAKE	1
?	PB8211	LENS, RED	1
?	VZ1912	BULB	1
?	PB8206	LIGHT, RETARD	1
?	PB8207	LENS, AMBER	1
?	VZ1912	BULB	1
?		WIPER, WINDSHIELD (SEE FIG 41751)	2	41751
?	SM2052	EYE, LIFTING	4
?	VN9057	CAPSCREW - 1/2" - 13NC X 1 3/4"	12
?	TR5445	LOCKWASHER - 1/2"	12
?	SM2898	GLASS, REAR - L.H.	1
?	SM5948	DOOR ASSEMBLY, L.H. (SEE INDEX)	1	60553
?	PC0841	WINDOW ASSEMBLY	1
?	SM2265	GLASS	1
?	SM2017	BAR, TAPPED (STRIKER)	2
?	1139538C1	CAPSCREW	2
?	SM2877	GLASS, FRONT - L.H.	1
?	SM0464	COVER, ACCESS	1
?	ED0108	SEAL STRIP	1
?	ED0109	SEAL STRIP	2
?	MM0595	CAPSCREW - M8 X 1.25 X 30	13
?	MM0470	LOCKWASHER - M8	13
?	WA5653	MACHINE SCREW - 1/4" X 1/2"	7
?	VD4460	LOCKNUT, NYLON - 1/4" - 20NC	7
?	SM0190	HINGE, ACCESS COVER	1
?	SM0189	COVER, HINGED	1
?	PB7001	FILTER, AIR	1
?	ED0110	SEAL STRIP	1
?	ED0112	SEAL STRIP	2
?	SM2899	GLASS, WINDSHIELD	1
?	SM4377	CHANNEL, RUBBER	1

Komatsu AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL parts catalog PDF

CAB ASSEMBLY (EK4250) (55087) in AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL. Diagram image and parts list.
