AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EJ8292	RADIO MODULE (SEE INDEX) (1)	1	55668
?	EK3605	WARNING LIGHTS MODULE (SEE INDEX) (1)	1	41821
?	SM5478	AIR FILTER RESTRICTOR GAUGE MODULE (SEE INDEX) (1)	1	55669
?	PB8658	SCREW, PANEL - M6 X 1.00	12
?	SM2055	PLATE	1
?	PC0251	SONALARM, SIGNAL	1
?	SM5122	BRACKET	1
?	MM0373	NUT - M5 X 0.8	1
?	MM0206	LOCKWASHER - M5	1
?	MM0207	LOCKWASHER - M6	18
?	MM0176	NUT, HEX - M6 X 1.00	18
?	PB4767	RELAY	1
?	31127R1	CAPSCREW - M6 X 12	6
?	PB9050	HOSE, VACUUM	2
?	PB9051	FITTING, SINGLE BARB W/FILTER	2
?	PB9056	FITTING, COMPRESSION - FEMALE	2
?	TM4777	TUBE, NYLON	2
?	PC0257	MODULE, DIMMER CONTROL	1
?	EK4227	DASH, OVERHEAD	1
?	SM5201	SPEAKER STRUCTURE	2
?	SM5176	SPEAKER	2
?	EF9758	HARNESS	2
?	WA3367	NUT ASSEMBLY	10
?	TA0602	FITTING, NYLON	2
?	TA0603	FITTING, NYLON	2
?	VZ4843	TIE, CABLE	4
?	SM2682	SCREW, COUNTER-SUNK	3
?		NOTE: (1) NOT SOLD AS AN ASSEMBLY.	-1
?		ORDER INDIVIDUAL PARTS.	-1

Komatsu AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL parts catalog PDF

OVERHEAD DASH MODULE (55667) in AFE50-CP 830E S/N A30842-A30844 ANTELOPE COAL. Diagram image and parts list.
