31127R1
|
CAPSCREW - M6 X 1.00 X 12 |
12 |
|
|
|
|
? |
SM0926
|
SCREW - M6 X 1.00 |
3 |
|
|
|
|
? |
MM0469
|
LOCKWASHER - M6 |
3 |
|
|
|
|
? |
SM2405
|
SEAL, WINDOW (INSIDE) |
1 |
|
|
|
|
? |
SM2548
|
SEAL, DOOR |
1 |
|
|
|
|
? |
EL2730
|
FRAME, DOOR - L.H. |
1 |
|
|
|
|
? |
TV6025
|
CAPSCREW - 1/4" - 20NC X 1 1/2" (STRIKER) |
1 |
|
|
|
|
? |
VN2882
|
JAM NUT - 1/4" - 20NC |
1 |
|
|
|
|
? |
KD0252
|
MACHINE SCREW |
4 |
|
|
|
|
? |
SD4235
|
LOCKWASHER - 1/4" (EXTERNAL TOOTH) |
4 |
|
|
|
|
? |
EL2746
|
INNER PANEL ASSEMBLY, L.H. (SEE INDEX) |
1 |
|
55947 |
|
|
? |
TG9225
|
LOCKNUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
MM0357
|
MACHINE SCREW - M6 X 1.00 X 12 |
1 |
|
|
|
|
? |
PC2166
|
WINDOW ASSEMBLY |
1 |
|
|
|
|
? |
EL2724
|
GLASS |
1 |
|
|
|
|
? |
BF5190
|
RUN, GLASS - TOP |
1 |
|
|
|
|
? |
BF5191
|
RUN, GLASS - SIDE |
2 |
|
|
|
|
? |
BF5189
|
BOTTOM FRAME ASSEMBLY |
1 |
|
|
|
|
? |
BF5194
|
SEAL, OUTSIDE - RUBBER FLOCK |
1 |
|
|
|
|
? |
BF2744
|
COVER, SCREW |
1 |
|
|
|
|
? |
SM2406
|
SCREW, SELF-TAPPING - #6 - 32NC X 3/8" |
22 |
|
|
|
|
? |
2048889R1
|
TRIM, BULK |
-1 |
|
|
|
|
? |
PC1828
|
HANDLE, PUSH BUTTON |
1 |
|
|
|
|
? |
31126R1
|
SCREW, MACHINE - M6 X 20 |
2 |
|
|
|
|
? |
31006R1
|
SCREW, MACHINE - M6 X 16 |
1 |
|
|
|
|
? |
SM2544
|
HINGE, DOOR |
1 |
|
|
|
|
? |
31154R1
|
CAPSCREW - M8 X 1.25 X 12 |
10 |
|
|
|
|
? |
SM2297
|
LATCH DOOR ASSEMBLY - L.H. |
1 |
|
|
|
|
? |
SM2263
|
LEVER, DOOR LATCH |
1 |
|
|
|
|
? |
SM2264
|
KNOB, DOOR LATCH |
2 |
|
|
|
|
? |
SM2354
|
SCREW - #10 - 24NC |
1 |
|
|
|
|
? |
SM2355
|
LOCKNUT - #10 - 24NC |
1 |
|
|
|
|
? |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
? |
SM2256
|
KEY, DOOR (1) |
1 |
|
|
|
|
? |
|
NOTE: (1) NOT SERVICED SEPARATELY. |
-1 |
|
|
