AFE57-AT 830E-1AC S/N A30182, A30186-A30187, A30191-A30193 CARDINAL RIVER / NORTH AMERICAN CONSTRUCTION

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	PC0292	HEATER, ENGINE OIL	2
?	PC0513	ADAPTER, METRIC	2
?	PC0707	HARNESS, ENGINE OIL HEATER	1
?	PB2306	VALVE, SHUT-OFF	2
?	PC0697	HEATER, ENGINE COOLANT	2
?	EJ9150	PLATE	2
?	H8136	CAPSCREW - 1/4" - 20NC X 1/2"	12
?	C5774	LOCKWASHER - 1/4"	12
?	WB0474	FITTING, STRAIGHT	3
?	HA7807	HOSE	1
?	PC1005	ADAPTER, METRIC	1
?	720462	CLAMP, VINYL - 5/16"	3
?	VH9969	STUD, WELD - 3/8" - 16NC X 3/4"	19
?	TR4436	FLAT WASHER - 3/8"	21
?	TC1233	NUT - 3/8" - 16NC	21
?	VN9907	CLAMP, VINYL - 5/8" I.D.	11
?	WB0365	FITTING, STRAIGHT	1
?	HA0946	HOSE	1
?	PB7005	CONNECTION, HOSE	2
?	PB7006	SEAL	2
?	PC0708	HARNESS, ENGINE COOLANT HEATER	1
?	WB0378	FITTING, ELBOW - 90 DEG	1
?	HA1402	HOSE	1
?	HA7806	HOSE	1
?	EH4356	RECEPTACLE (INCLUDES CABLE TO HOTSTART BOX)	1
?	PB1641	RECEPTACLE, MALE	1
?	PB7234	BOX BACK	1
?	VZ1368	CORD GRIP	1
?	PB1642	PLUG, FEMALE (1)	1
?	TZ1170	PLATE, MOUNTING	1
?	C5747	CAPSCREW - 5/16" - 18NC X 3/4"	2
?	C1538	LOCKWASHER - 5/16"	2
?	TC1565	CLAMP, VINYL - 15/16" I.D.	4
?	EJ5557	BOX, HOTSTART (SEE INDEX)	1	41817
?	TH0170	BLOCK, TAPPED	4
?	VZ1368	GRIP, CORD	1
?	VZ1369	LOCKNUT, CONDULET	1
?	EJ2096	HARNESS, HYDRAULIC TANK	1
?	TC6058	CLAMP, VINYL - 1 1/2" I.D. (FOR ITEMS 10 AND 24)	2
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	2
?	EF9855	PLATE, BENT	2
?		NOTE: (1) MATES WITH EH4356. CUSTOMER ADDS WIRING.	-1

Komatsu AFE57-AT 830E-1AC S/N A30182, A30186-A30187, A30191-A30193 CARDINAL RIVER / NORTH AMERICAN CONSTRUCTION parts catalog PDF

ENGINE OIL/COOLANT HEATERS (HOTSTART) (42333) in AFE57-AT 830E-1AC S/N A30182, A30186-A30187, A30191-A30193 CARDINAL RIVER / NORTH AMERICAN CONSTRUCTION. Diagram image and parts list.
