AFE57-HT 830E-1AC S/N A40966, A40987 & A40990 - A40992 SEVERSTAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-57-10021	SEAT BELT ASSEMBLY	1
?	XA5492	TETHER KIT, EXTERNAL	2
?	XA5524	BACKREST ASSEMBLY	1
?	XA5489	COVER, BACKREST	1
?	XA5490	HEADREST	1
?	XA5526	LUMBAR ASSEMBLY	1
?	XA5536	CUSHION ASSEMBLY, SEAT	1
?	XA5505	COVER, SEAT CUSHION	1
?	XA5506	HANDLE, SEAT CUSHION ADJUSTER	1
?	XA5491	RISER	1
?	XA5518	COVER, REAR	1
?	XA5493	BOLT KIT, SHOULDER	1
?	XA5529	HANDLE ASSEMBLY, BACKREST ADJUSTMENT	1
?	XA5495	ADJUSTER, INCLINATION	1
?	XA5530	SIDE COVER, RH	1
?	XA5531	VALVE (RH)	1
?	XA5535	FRAME ASSEMBLY, SEAT	1
?	XA5532	ADJUSTER, SHOCK ABSORBER	1
?	XA5497	SHOCK ABSORBER, ADJUSTABLE	1
?	XA5498	SPRING, AIR	1
?	BF0501	RELAY	1
?	XA5503	SLIDE SET	1
?	XA5504	HANDLE, SLIDE	1
?	XA5499	COMPRESSOR	1
?	XA5496	ADJUSTER, WEIGHT/HEIGHT	1
?	XA5502	FASTENERS KIT	1
?	XA5501	BELLOWS	1
?	XA5517	COVER, FRONT	1
?	XA5528	BOLT, LOCKING	1
?	XA5494	GLIDES	1
?	XA5964	SIDE COVER, LH	1
?	XA5537	COVER, SHOULDER BELT	1

Komatsu AFE57-HT 830E-1AC S/N A40966, A40987 & A40990 - A40992 SEVERSTAL parts catalog PDF

PASSENGER SEAT 58E-57-10031 (43072) in AFE57-HT 830E-1AC S/N A40966, A40987 & A40990 - A40992 SEVERSTAL. Diagram image and parts list.
