AFE57-GU 830E-1AC S/N A40884 - A40887 & A40895 - A40899 MANTOS BLANCOS

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	XB5826	PLATE, BENT	1
?	WB3470	DECAL, LADDER LIGHT (SPANISH)	1
?	WB3473	DECAL, EMERGENCY ENGINE SHUTDOWN (SPANISH)	1
?	58E-06-02090	BOX, ISOLATION	1
?	WB3474	DECAL, ISOLATION STATION (SPANISH)	1
?	EM6700	BOX, EMERGENCY ENGINE SHUTDOWN	1
?	58E-06-01880	PLATE	1
?	MM0343	SCREW - M4 X 0.7 X 16	4
?	MM0378	LOCKWASHER - M4	4
?	MM0605	CAPSCREW - M10 X 1.50 X 25	3
?	MM0178	NUT - M10 X 1.50	6
?	08193-21012	CLIP	1
?	MM0461	FLAT WASHER - M10	14
?	MM0594	CAPSCREW - M8 X 1.25 X 25	11
?	MM0470	LOCKWASHER - M8	11
?	MM0460	FLAT WASHER - M8	11
?	WB3098	CLAMP, CUSHION - 3/8"	7
?	EM7826	HARNESS, EMERGENCY ENGINE SHUTDOWN	1
?	PB6842	HOOK, RUBBER	1
?	C1639	CAPSCREW - 5/16" - 18NC X 2"	1
?	VN9951	LOCKNUT - 5/16" - 18NC	1
?	VA2826	COVER	1
?	EM7830	HARNESS, LADDER LIGHT JUMPER	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	2
?	MM0713	FLAT WASHER - M10	2
?	MM0471	LOCKWASHER - M10	11
?	VN7129	SCREW - #6 - 32NC X 5/8"	6
?	DF4944	LOCKWASHER - #6	6
?	VN9764	FLAT WASHER - #6	6
?	VA2828	SWITCH	1
?	PB9072	CONDULET, SINGLE GANG	1
?	MM0358	SCREW - M6 X 1.00 X 16	2
?	MM0469	LOCKWASHER - M6	2

Komatsu AFE57-GU 830E-1AC S/N A40884 - A40887 & A40895 - A40899 MANTOS BLANCOS parts catalog PDF

ISOLATION BOX 1/3 58E-06-01320 (43527) in AFE57-GU 830E-1AC S/N A40884 - A40887 & A40895 - A40899 MANTOS BLANCOS. Diagram image and parts list.
