AFE57-GU 830E-1AC S/N A40884 - A40887 & A40895 - A40899 MANTOS BLANCOS

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PC1375	SWITCH, PUSH - PULL	1
?	WB3472	PLATE, STARTER DISCONNECT (SPANISH)	1
?	58E-06-01990	LED	6
?	WB3475	PLATE, PROPEL DISCONNECT (SPANISH)	1
?	PC2527	LEVER, LOCKOUT	1
?	WB3098	CLAMP, CUSHION - 3/8"	3
?	58E-06-10100	BUS BAR	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	6
?	MM0471	LOCKWASHER - M10	6
?	MM0178	NUT - M10 X 1.50	6
?	58E-06-10420	BUS BAR	1
?	DF3500	LOCKNUT - 1/2" - 13NC	4
?	58E-06-10200	BUS BAR	1
?	58E-06-01890	BUS BAR	1
?	MM0578	CAPSCREW - M6 X 1.00 X 10	4
?	SD4235	LOCKWASHER - 1/4"	4
?	TD1549	NUT - 1/4" - 20NC	8
?	DC3584	LOCKWASHER - 1/4"	8
?	VN9773	FLAT WASHER - 1/4"	8
?	TC1231	LOCKWASHER - 3/8"	2
?	MM0461	FLAT WASHER - M10	12
?	HD8390	FLAT WASHER - #10	2
?	DC3101	LOCKWASHER - #10	6
?	PC2528	SWITCH	1
?	58E-06-01310	HARNESS, ISOLATION BOX	1
?	58B-06-11530	CONNECTOR, JUNCTION BUSS (KEY B)	1
?	PC2834	DIODE - 4 AMP	1
?	58E-06-10020	RELAY	3
?	TR1306	CAPSCREW - 1/4" - 20NC X 1"	8
?	EC1725	SWITCH	2
?	MM0594	CAPSCREW - M8 X 1.25 X 25	4
?	MM0470	LOCKWASHER - M8	4
?	MM0460	FLAT WASHER - M8	4
?	EK9945	PLATE, BENT	2
?	WB3471	PLATE, MASTER DISCONNECT (SPANISH)	1
?	MM0341	MACHINE SCREW - M4 X 0.7 X 10	14
?	MM0378	LOCKWASHER - M4	12
?	WB3476	DECAL, PUSH BUTTON (SPANISH)	1

Komatsu AFE57-GU 830E-1AC S/N A40884 - A40887 & A40895 - A40899 MANTOS BLANCOS parts catalog PDF

ISOLATION BOX 2/3 58E-06-01320 (43529) in AFE57-GU 830E-1AC S/N A40884 - A40887 & A40895 - A40899 MANTOS BLANCOS. Diagram image and parts list.
