PB7202
|
INSULATOR |
2 |
|
|
|
|
? |
ED7468
|
ROD, THREADED - 5/16" |
2 |
|
|
|
|
? |
SC4174
|
LOCKWASHER - 5/16" |
4 |
|
|
|
|
? |
TD1684
|
NUT - 5/16" - 18NC |
2 |
|
|
|
|
? |
TV0177
|
FLAT WASHER - 5/16" |
4 |
|
|
|
|
? |
EK0731
|
ROD, THREADED - M6 |
8 |
|
|
|
|
? |
MM0176
|
NUT - M6 X 1.00 |
26 |
|
|
|
|
? |
MM0469
|
LOCKWASHER - M6 |
17 |
|
|
|
|
? |
MM0459
|
FLAT WASHER - M6 |
23 |
|
|
|
|
? |
TA7409
|
INSULATOR, STAND-OFF |
1 |
|
|
|
|
? |
ED0913
|
ROD, THREADED - 1/4" |
1 |
|
|
|
|
? |
TD1549
|
NUT - 1/4" - 20NC |
1 |
|
|
|
|
? |
DC3584
|
LOCKWASHER - 1/4" |
2 |
|
|
|
|
? |
TR1307
|
FLAT WASHER - 1/4" |
2 |
|
|
|
|
? |
PC1110
|
CONVERTER (24-12 VDC, 60 AMP) |
1 |
|
|
|
|
? |
WB3479
|
NAME PLATE - CB60 |
1 |
|
|
|
|
? |
ED4418
|
BRACKET |
1 |
|
|
|
|
? |
XB2268
|
MOUNTING BRACKET ASSEMBLY |
1 |
|
|
|
|
? |
XB2266
|
MOUNT, BRACKET |
1 |
|
|
|
|
? |
EK9239
|
BRACKET |
9 |
|
|
|
|
? |
MM0470
|
LOCKWASHER - M8 |
36 |
|
|
|
|
? |
MM0177
|
NUT - M8 X 1.25 |
36 |
|
|
|
|
? |
MM0460
|
FLAT WASHER - M8 |
36 |
|
|
|
|
? |
TC1234
|
CAPSCREW - 3/8" - 16NC X 3/4" |
9 |
|
|
|
|
? |
TC1231
|
LOCKWASHER - 3/8" |
9 |
|
|
|
|
? |
TR4436
|
FLAT WASHER - 3/8" |
9 |
|
|
|
|
? |
EK3808
|
RELAY BOARD ASSEMBLY - RB1 (SEE FIG 55612) |
1 |
|
55612 |
|
|
? |
EK3803
|
RELAY BOARD ASSEMBLY - RB3 (SEE FIG 55612) |
1 |
|
55612 |
|
|
? |
EK3806
|
RELAY BOARD ASSEMBLY - RB4 (SEE FIG 55612) |
1 |
|
55612 |
|
|
? |
EK3811
|
RELAY BOARD ASSEMBLY - RB5 (SEE FIG 55612) |
1 |
|
55612 |
|
|
? |
TZ7377
|
NAME PLATE - 24 VDC |
1 |
|
|
|
|
? |
WB2281
|
NAME PLATE - LUBE TIMER |
1 |
|
|
|
|
? |
WB2303
|
NAME PLATE - GB31 |
1 |
|
|
|
|
? |
TZ7378
|
NAME PLATE - 12 VDC |
1 |
|
|
|
|
? |
WB3239
|
NAME PLATE - 12 VCN |
1 |
|
|
|
|
? |
WB3238
|
NAME PLATE - DOKG |
1 |
|
|
|
|
? |
WB3237
|
NAME PLATE - RB9 |
1 |
|
|
|
|
? |
WB2836
|
NAME PLATE - 12V POWER RELAY |
1 |
|
|
|
|
? |
WB2289
|
NAME PLATE - CONTROL POWER RELAY |
1 |
|
|
|
|
? |
EM8245
|
HARNESS, AUXILIARY BOX (P301 - P305) |
1 |
|
|
|
|
? |
WB2835
|
NAME PLATE - KEY SWITCH POWER RELAY |
1 |
|
|
|
|
? |
WB3298
|
NAME PLATE - GROUND LEVEL POWER RELAY |
1 |
|
|
|
|
? |
WB2280
|
NAME PLATE - RB7 |
1 |
|
|
|
|
? |
EC8824
|
NAME PLATE - RB6 |
1 |
|
|
|
|
? |
EL7628
|
NAME PLATE - INCLINOMETER |
1 |
|
|
|
|
? |
EC8825
|
NAME PLATE - DB1 |
1 |
|
|
|
|
? |
WB2733
|
NAME PLATE - RB8 |
1 |
|
|
|
|
? |
EC8819
|
NAME PLATE - RB1 |
2 |
|
|
|
|
? |
EC8821
|
NAME PLATE - RB3 |
2 |
|
|
|
|
? |
EC8822
|
NAME PLATE - RB4 |
2 |
|
|
|
|
? |
EC8823
|
NAME PLATE - RB5 |
2 |
|
|
|
|
? |
PB8460
|
CIRCUIT BREAKER |
1 |
|
|
|
|
? |
MM0584
|
CAPSCREW - M6 X 1.00 X 30 |
5 |
|
|
|
|
? |
EG2305
|
BUS BAR |
1 |
|
|
|
|
? |
WB3521
|
NAME PLATE - EMT |
1 |
|
|
|
|
? |
WB3522
|
NAME PLATE - PMT |
1 |
|
|
|
|
? |
WB3731
|
NAME PLATE - HORN RELAY |
1 |
|
|
|
|
? |
|
(FOR VIEWS A-A THROUGH D-D, SEE THE FOLLOWING PAGE.) |
-1 |
|
|
