AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EK1413	JUNCTION BOX ASSEMBLY - REAR (SEE INDEX)	1	60960
?	MM0603	CAPSCREW - M10 X 1.50 X 16	4
?	MM0461	FLAT WASHER - M10	7
?	MM0178	NUT - M10 X 1.50	3
?	WB3097	CLAMP, CUSHIONED - 1/2"	2
?	WB3098	CLAMP, CUSHIONED - 3/8"	1
?	WB3093	CLAMP, CUSHIONED - 1"	4
?	C0312	LOCKWASHER - 3/8"	8
?	C1521	NUT - 3/8" - 16NC	8
?	SP6153	LOCKWASHER - 3/8" (EXTERNAL - INTERNAL TOOTH)	4
?	736131C2	ALARM, BACKUP	2
?	C5753	CAPSCREW - 3/8" - 16NC X 4"	4
?	EK5647	HARNESS, BLOWER PRESSURE SWITCH	1
?	EK2302	HARNESS, AXLE HOUSING	1
?	SP8708	LOCKWASHER - 5/16" (EXTERNAL - INTERNAL TOOTH)	6
?	PC1913	STOP/TAIL LIGHT - RED (LED)	2
?	AK4695	LENS\REFLECTOR - STOP/TAIL - RED (LED)	1
?	AK4705	HOUSING ASSEMBLY - UNIVERSAL	1
?	PC1914	RETARD LIGHT - AMBER (LED)	2
?	AK4696	LENS\REFLECTOR - RETARD/TURN - AMBER (LED)	1
?	AK4704	HOUSING ASSEMBLY - UNIVERSAL	1
?	AK7513	BACKUP LIGHT ASSEMBLY (SEE FIG 60883)	2	60883

Komatsu AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO parts catalog PDF

REAR LIGHTS & BACKUP HORN INSTALLATION (61124) in AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO. Diagram image and parts list.
