AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	SM2712	PLATE, WARNING LIGHT	1
?	EL4144	LEXAN OVERLAY	1
?	EM4315	HARNESS, WARNING LIGHT	1
?	EM4316	SOCKET, WARNING LIGHT	1
?	SM4443	FLASHER ASSEMBLY - CLEAR LENS	30
?	VL6234	BULB	30
?	SM4473	DECAL, CYLINDER OIL TEMPERATURE	2
?	SM5083	DECAL, CYLINDER OIL LEVEL	1
?	SM5052	DECAL, PARKING BRAKE	1
?	EJ8283	DECAL, CRANK MOTOR FAILURE	1
?	SM5103	DECAL, NO POWER (PROPULSION SYSTEM)	1
?	SM5102	DECAL, NO PROPULSION	1
?	SM5065	DECAL, STEERING SYSTEM PRESSURE	1
?	EG3303	DECAL, LOW LUBE PRESSURE	1
?	SM5056	DECAL, BRAKE	1
?	SM4470	DECAL, BACKUP LIGHTS	1
?	SM5099	DECAL, PROPULSION SYSTEM WARNING	1
?	SM5106	DECAL, PROPULSION SYSTEM REST	1
?	SM5053	DECAL, ACCUMULATOR PRE-CHARGE PRESSURE	1
?	SM5089	DECAL, CIRCUIT BREAKER TRIPPED	1
?	SM5075	DECAL, BODY-UP	1
?	EM4308	DECAL, TIMED ENGINE SHUTDOWN	1
?	SM5098	DECAL, PROPULSION SYSTEM TEMPERATURE	1
?	SM5105	DECAL, PROPULSION SYSTEM NOT READY	1
?	SM4315	DECAL, NOT USED	1
?	SM5084	DECAL, CYLINDER OIL FILTER	1
?	SM5070	DECAL, RETARDER	1
?	SM5071	DECAL, RETARDER SPEED CONTROL	1
?	EM0008	DECAL, MAINTENANCE (RED)	1
?	SM5097	DECAL, REDUCED PROPULSION	1
?	SM5057	DECAL, LOW BRAKE OIL PRESSURE	1
?	SM5078	DECAL, LOW FUEL LEVEL	1
?	SM5063	DECAL, ENGINE SHUTDOWN	1
?	SM5076	DECAL, CHECK ENGINE	1
?	SM5058	DECAL, BATTERY CHARGE	1
?	SM5101	DECAL, RETARD AT CONTINUOUS LEVEL	1
?		NOTE: MODULE NOT SERVICED AS AN ASSEMBLY.	-1
?		ORDER INDIVIDUAL COMPONENT PARTS.	-1

Komatsu AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO parts catalog PDF

WARNING LIGHTS MODULE (EM4309) (61223) in AFE59-BM 930E-4 S/N A30712 - A30714 CODELCO. Diagram image and parts list.
