SEAT SUSPENSION ASSEMBLY XA5816 | AFE57-JJ 830E-1AC S/N A41035 COLOWYO

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
1	XA4923	SHAFT, BEARING	4
2	XA4920	HOUSING, UPPER	1
3	XA4962	NUT, CENTERLOCK - 3/8" - 16NC	10
4	XA4932	BRACKET, CABLE	1
5	XA4965	CAPSCREW - 1/4" - 20NC X 5/8"	2
6	XA4952	CAPSCREW - 1/4" - 20NC X 1 1/2"	1
7	XA4951	CAPSCREW - #6 - 32NC X 1/2"	1
8	XA4931	KNOB	1
9	XA4954	SPRING, COMPRESSION	1
10	XA4946	BALL, BEARING	1
11	XA4950	LOCKNUT - #6 - 32NC	1
12	XA4961	LOCKNUT - 1/4" - 20NC	5
13	XA4929	LINK, NARROW TOGGLE	1
14	XA4966	CAPSCREW - 3/8" - 16NC X 1/2"	1
15	XA4943	TUBE, BEARING	12
16	XA4935	SHOULDER BOLT	2
17	XA4957	LOCKWASHER	2
18	XA4963	FLAT WASHER	2
19	XA4930	RETAINER, BUMPER	2
20	XA4960	CAPSCREW - #8 - 32NC X 1 1/4"	2
21	XA4947	FITTING, ELBOW - 90 DEG (1)	1
22	XA4939	BUMPER	2
23	XA4959	SCREW - 1/4" - 20NC X 1"	2
24	XA4925	TETHER, BOLT	2
25	XA4924	ARM, SCISSORS	1
26	XA4938	SHOCK ABSORBER	1
27	58E-98-00210	CLAMP, COMPRESSOR	1
28	XA4928	LINK, WIDE TOGGLE	1
29	XA4941	SPRING, AIR	1
30	XA4921	HOUSING, LOWER	1
31	XA4958	SCREW - 3/8" - 16NC	1
32	XA4955	CLIP	28
33	XA4942	BOOT, SUSPENSION	1
34	XA5791	COMPRESSOR	1
35	XA4956	TUBING, NYLON - 5/32" (PRESSURE) (1)/(2)	1
36	XA4948	TUBING, CONVOLUTED (VENT)	1
37	XA4933	SHOULDER BOLT	2
38	XA4922	SHOCK ABSORBER, ADJUSTABLE	1
39	XA4937	WASHER, SPACER	4
40	XA4940	BEARING	4
41	58E-98-10400	SHAFT, BEARING - LONG	1
42	XA4926	SHAFT, BEARING - SHORT	1
43	XA4964	FLAT WASHER	2
44	XA4927	HARNESS, SEAT COMPRESSOR	1
45	XA4945	TIE, CABLE (1)	1
NS\|46	XA5074	NOTE: (1) INCLUDED IN XA5074 AIR LINE SERVICE KIT.	-1
NS\|47		(2) NOT SERVICED SEPARATELY. ORDER XA5074.	-1
