AFE59-FW 930E-4 S/N A31849 & A31860 CERREJON

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-04-00080	MOUNT	1
?	WB0466	FITTING, STRAIGHT	1
?	C5771	PLUG, PIPE - 1/2"	1
?	PB9212	RECEIVER ASSEMBLY (ENGINE OIL)	1
?	WB0947	LOCKNUT, BULKHEAD - 1 5/8" - 12NC	1
?	PB9211	RECEIVER ASSEMBLY (COOLANT)	1
?	WB0945	LOCKNUT, BULKHEAD - 1 3/16" - 12NC	1
?	PB9213	RECEIVER ASSEMBLY (HYDRAULIC OIL)	1
?	WB0948	LOCKNUT, BULKHEAD - 1 7/8" - 12NC	1
?	EK7400	DECAL, SERVICE CENTER	1
?	WB0594	FITTING, STRAIGHT	1
?	WB0585	FITTING, STRAIGHT	1
?	WB0600	FITTING, STRAIGHT	1
?	WB0364	FITTING, STRAIGHT	1
?	MM0620	CAPSCREW - M12 X 1.75 X 40	4
?	MM0714	FLAT WASHER - M12 (HARDENED)	8
?	MM0179	NUT - M12 X 1.75	4
?	HA8278	HOSE (TO HYDRAULIC TANK)	1
?	HA8280	HOSE (TO RADIATOR)	1
?	HA2873	HOSE (TO ENGINE OIL RESERVE TANK)	1
?	HA8300	HOSE (TO AUTO LUBE PUMP)	1
?	SG3146	GROMMET	1
?	WB0265	FITTING, ELBOW - 90 DEG	1
?	TC8757	BUSHING, PIPE - 2" X 1"	1
?	WA2919	FITTING, ELBOW - 90 DEG	1
?	MM0178	NUT - M10 X 1.50	20
?	MM0471	LOCKWASHER - M10	20
?	MM0461	FLAT WASHER - M10	20
?	WB3096	CLAMP, CUSHIONED - 1 1/4"	28
?	TY8375	SPACER	3
?	WB3092	CLAMP, CUSHIONED - 7/8"	5
?	EK9883	SPACER	13
?	EM7532	SPACER	5

Komatsu AFE59-FW 930E-4 S/N A31849 & A31860 CERREJON parts catalog PDF

SERVICE CENTER - LH (62499) in AFE59-FW 930E-4 S/N A31849 & A31860 CERREJON. Diagram image and parts list.
