AFE59-FF 930E-4 S/N A31624 & A31628 ANTELOPE COAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-98-00340	BLOCK, CONTROL	1
?	58E-98-00420	CAPSCREW, HEX HEAD - 5/16" - 18NC X 2 3/4"	4
?	VE9610	PLUG, HOLLOW HEX	8
?	VE9613	O-RING	8
?	BF1731	ORIFICE	1
?	VE9607	PLUG, HOLLOW HEX	1
?	VE9612	O-RING	1
?	58E-98-00400	CAP, SPRING	1
?	BF1330	O-RING	3
?	BF3511	SPRING, 4-WAY VALVE	1
?	58E-98-00380	SPOOL, CONTROL VALVE	1
?	58E-98-00390	CAP, SPOOL	1
?	BF1680	PLUG	1
?	58E-98-00410	PLUG, STOP	1
?	58E-98-00430	PIN, PUSH	1
?	BF2184	O-RING	1
?	BF2186	RING, BACKUP	1
?	58E-98-00450	O-RING	1
?	58E-98-00460	POPPET, VALVE	1
?	58E-98-00440	SEAT, VALVE	1
?	BF2183	SPRING	1
?	BF2178	SCREW, ADJUSTING	1
?	BF2179	BONNET, MODULE	1
?	BF3513	O-RING	1
?	BF2187	CAP, ADJUSTER	1
?	BF2189	PLUG	1
?	VE9611	O-RING	1

Komatsu AFE59-FF 930E-4 S/N A31624 & A31628 ANTELOPE COAL parts catalog PDF

CONTROL ASSEMBLY 58E-98-00370 (62383) in AFE59-FF 930E-4 S/N A31624 & A31628 ANTELOPE COAL. Diagram image and parts list.
