AFE59-GY 930E-4 S/N A32045 - A32046 & A32058 - A32061 VALE CARAJAS

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58F-06-00514	HARNESS, LEFT REAR FRAME RAIL	1
?	PC2834	DIODE - 4 AMP (D26, D88)	1
?	TF6924	CLAMP, VINYL - 1 3/4"	6
?	MM0178	NUT - M10 X 1.50	21
?	MM0471	LOCKWASHER - M10	21
?	MM0461	FLAT WASHER - M10	21
?	EK9883	SPACER	3
?	WB1302	CLAMP, CUSHIONED - 5/16"	1
?	08193-21012	CLIP	3
?	WB1303	CLAMP, CUSHIONED - 3/4"	1
?	WB3855	CLAMP, CUSHIONED - 13/16"	1
?	WB1304	CLAMP, CUSHIONED - 9/16"	3
?	WB3092	CLAMP, CUSHIONED - 7/8"	1
?	WB3097	CLAMP, CUSHIONED - 1/2"	1
?	WB3098	CLAMP, CUSHIONED - 3/8"	3
?	WB1301	CLAMP, CUSHIONED - 1/4"	3
?	MM0082	CAPSCREW - M10 X 1.50 X 80	2
?	08192-12100	BODY, RECEPTACLE CONNECTOR	1

Komatsu AFE59-GY 930E-4 S/N A32045 - A32046 & A32058 - A32061 VALE CARAJAS parts catalog PDF

LEFT REAR FRAME RAIL HARNESS (63278) in AFE59-GY 930E-4 S/N A32045 - A32046 & A32058 - A32061 VALE CARAJAS. Diagram image and parts list.
