58F-32-40010
|
SPINDLE, HUB AND BRAKE ASSEMBLY |
1 |
|
|
|
|
? |
EM4976
|
HUB ASSEMBLY |
1 |
|
|
|
|
? |
EJ6978
|
HUB, WHEEL |
1 |
|
|
|
|
? |
EH0826
|
STUD W/ HEAD |
57 |
|
|
|
|
? |
EH7192
|
O-RING (1) |
1 |
|
|
|
|
? |
EL2876
|
SHIM - .005 (1) |
3 |
|
|
|
|
? |
EL2877
|
SHIM - .007 (1) |
4 |
|
|
|
|
? |
EL2878
|
SHIM - .020 (1) |
6 |
|
|
|
|
? |
EH9522
|
COVER |
1 |
|
|
|
|
? |
WB1199
|
PLUG, MAGNETIC |
1 |
|
|
|
|
? |
EH7190
|
O-RING (1) |
1 |
|
|
|
|
? |
XB7696
|
RETAINER, BEARING |
1 |
|
|
|
|
? |
TY2148
|
FLAT WASHER - 1" (HARDENED) |
8 |
|
|
|
|
? |
VM8258
|
CAPSCREW - 1" - 8NC X 3 3/4" |
8 |
|
|
|
|
? |
PC3060
|
BEARING ASSEMBLY, OUTER (1) |
1 |
|
|
|
|
? |
C1540
|
LOCKWASHER - 1/2" |
12 |
|
|
|
|
? |
C1614
|
CAPSCREW - 1/2" - 13NC X 1 1/2" |
12 |
|
|
|
|
? |
EH7195
|
SEAL, O-RING (1) |
1 |
|
|
|
|
? |
ED3755
|
SHIM - .020 (1) |
54 |
|
|
|
|
? |
EJ7475
|
GEAR, SPEED SENSOR |
1 |
|
|
|
|
? |
EG7694
|
SPINDLE |
1 |
|
|
|
|
? |
PC3059
|
BEARING ASSEMBLY, INNER (1) |
1 |
|
|
|
|
? |
562-22-32290
|
PIN (1) |
2 |
|
|
|
|
? |
ED3772
|
SPACER, BEARING |
1 |
|
|
|
|
? |
TY2149
|
FLAT WASHER (HARDENED) |
89 |
|
|
|
|
? |
WA5660
|
CAPSCREW - 1 1/4" - 12NF X 7 1/2" (12 PT) |
32 |
|
|
|
|
? |
EH7194
|
O-RING (1) |
1 |
|
|
|
|
? |
WA5669
|
CAPSCREW - 1 1/4" - 12NF X 3 1/2" (12 PT) |
57 |
|
|
|
|
? |
EH7196
|
SEAL, O-RING (1) |
1 |
|
|
|
|
? |
ED3775
|
ADAPTER, BRAKE |
1 |
|
|
|
|
? |
WA0360
|
FLAT WASHER - 1/2" (HARDENED) |
12 |
|
|
|
|
? |
VN9065
|
CAPSCREW - 1/2" - 13NC X 2" |
12 |
|
|
|
|
? |
58F-32-40000
|
FRONT BRAKE ASSEMBLY (SEE INDEX) |
1 |
|
62918 |
|
|
? |
WB1057
|
REDUCER |
1 |
|
|
|
|
? |
PB6528
|
COUPLING, DIAGNOSTIC |
1 |
|
|
|
|
? |
PB6041
|
CAP, DUST |
1 |
|
|
|
|
? |
WA2567
|
FITTING, CAPNUT |
1 |
|
|
|
|
? |
PC0651
|
SEAL ASSEMBLY (4) |
1 |
|
|
|
|
? |
BF4837
|
SEAL, TORIC |
2 |
|
|
|
|
? |
BF4116
|
RING, SEAL |
2 |
|
|
|
|
? |
BF4117
|
TOOL, INSTALLATION (2) |
1 |
|
|
|
|
? |
PC1431
|
SEAL, OIL (4) |
1 |
|
|
|
|
? |
EK5888
|
CARRIER, SEAL |
1 |
|
|
|
|
? |
EL9501
|
BRACKET, MOUNTING |
6 |
|
|
|
|
? |
D2930
|
CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" (3) |
6 |
|
|
|
|
? |
C1612
|
CAPSCREW - 1/2" - 13NC X 1" |
12 |
|
|
|
|
? |
WA0360
|
FLAT WASHER - 1/2" (HARDENED) |
12 |
|
|
|
|
? |
58F-SM-AK030
|
NOTE: (1) INCLUDED IN 58F-SM-AK030 SPINDLE |
-1 |
|
|
|
|
? |
|
MAINTENANCE KIT. |
-1 |
|
|
|
|
? |
|
(2) NOT INCLUDED IN SEAL ASSEMBLY. |
-1 |
|
|
|
|
? |
|
(3) USED FOR ASSEMBLY AND STORAGE ONLY. |
-1 |
|
|
|
|
? |
|
REMOVE WHEN INSTALLED ON THE TRUCK. |
-1 |
|
|
|
|
? |
58F-BK-AK070
|
(4) INCLUDED IN 58F-BK-AK070 FRONT BRAKE |
-1 |
|
|
|
|
? |
|
SEAL KIT. |
-1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
