TOOL GROUP 1/2 58F-98-00020 | AFE62-BW 930E-4SE S/N A32123 COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
1	EH4638	TOOL, SLEEVE ALIGNMENT	1
2	EH8687	ROLLER ASSEMBLY	2
2	58F-98-01020	MOUNT, ROLLER	2
2	PC0706	BEARING	2
2	TG9449	RING, RETAINING (BEARING)	2
2	TG1680	RING, RETAINING (ROLLER RING)	4
2	C1645	CAPSCREW - 3/4" - 10NC X 2 1/4"	12
2	C1542	LOCKWASHER - 3/4"	12
2	EH8686	RING, ROLLER	2
3	PC2525	HARNESS, WIRING - PLM DOWNLOAD	1
4	EF9302	WEAR INDICATOR ASSEMBLY	4
4	EB1723	CAP, INDICATOR	4
4	EF9301	PIN, WEAR INDICATOR	4
4	WA0010	O-RING, WEAR INDICATOR PIN	4
4	TL3995	O-RING	4
4	EB4813	HOUSING, WEAR INDICATOR	4
4	SV9812	O-RING	4
5	TZ2100	SOCKET - 1 7/8"	1
5	TZ2727	SOCKET - 2 1/4"	1
5	TZ2729	SOCKET - 1 1/4"	1
6	58C-98-00310	SOCKET - 1 1/4" (THIN WALL)	1
7	TZ2730	ADAPTER - 1" X 1 1/2"	1
7	TZ2731	ADAPTER - 3/4" X 1"	1
8	TZ2733	HANDLE, TUBULAR	1
9	TZ2734	ADAPTER, TORQUE - 3/4"	1
10	PB8326	WRENCH, OFFSET - 1 7/16"	1
11	TR0532	EXTENSION - 8" LONG	1
11	TR0533	EXTENSION - 17" LONG	1
12	EK3798	BRAKE ASSEMBLY TOOL GROUP	1
12	D9105	CAPSCREW - 1/2" - 13NC X 8"	4
12	ED3757	BAR, FLAT	2
12	ED3758	PIPE	4
12	C1615	CAPSCREW - 1/2" - 13NC X 1 3/4"	4
12	C1540	LOCKWASHER - 1/2"	8
13	XB7075	FITTING, ASSEMBLY	1
14	58B-06-00800	CUSTOM METER KIT, 0-2000 VDC (SEE FIG 43458)	1	43458
15	PB9067	CONNECTOR, BULKHEAD (BATTERY JUMPER)	2
16	EH7817	TOOL, ALIGNMENT (UPPER HOIST PIN)	1
17	XB5777	HOSE (STEERING SYSTEM FLUSHING)	1
NS\|40		NOTE: NS = NOT SHOWN	-1
NS\|41	PC3074	BLOCK, FLUSHING (1)	2
NS\|42		NOTE: (1) NOT PART OF TOOL GROUP.	-1
NS\|43		INCLUDED AS SHIP LOOSE COMPONENT.	-1
