ENGINE OIL RESERVE SYSTEM 1/2 | AFE62-BW 930E-4SE S/N A32123 COLLAHUASI

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE62-BW 930E-4SE S/N A32123 COLLAHUASI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?		TANK, OIL RESERVE (1)	1
?	C1531	NUT - 1" - 8NC	4
?	C1544	LOCKWASHER - 1"	4
?	WB0267	FITTING, ELBOW - 90 DEG	2
?	58F-60-40240	HOSE	1
?	WB0293	FITTING, ELBOW - 45 DEG	1
?	58B-60-10010	HOSE	1
?	58E-61-00020	TUBE, WITHDRAWAL (FLANGED)	1
?	58F-60-10120	GASKET	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	2
?	MM0471	LOCKWASHER - M10	13
?	MM0461	FLAT WASHER - M10	15
?	EJ3557	PAD, TAPPED	1
?	PC1262	ADAPTER, STRAIGHT	1
?	WA4896	FITTING	1
?	MM0178	NUT - M10 X 1.50	8
?	WB1308	CLAMP, CUSHIONED - 1 1/16"	10
?	WB3857	CLAMP, CUSHIONED - 1 3/16"	10
?	EK9883	SPACER	3
?	EM3586	SPACER	2
?	MM0607	CAPSCREW - M10 X 1.50 X 35	3
?	MM0604	CAPSCREW - M10 X 1.50 X 20	1
?	WB0376	FITTING, ELBOW - 90 DEG	1
?	XB1392	BRACKET	1
?	MM0618	CAPSCREW - M12 X 1.75 X 30	3
?	MM0714	FLAT WASHER, HARDENED - M12	5
?	MM0620	CAPSCREW - M12 X 1.75 X 40	2
?	WB3917	NUT, COUPLING	2
?	MM0603	CAPSCREW - M10 X 1.50 X 16	1
?	58B-06-20020	BRACKET	1
?	58B-03-00670	BRACKET	1
?	58F-02-40960	CUP ASSEMBLY (2)	1
?	WB0467	FITTING, STRAIGHT	1
?	58E-61-00221	NOTE: (1) INCLUDED IN 58E-61-00221 RESERVE SYSTEM KIT.	-1
?		(2) INSTALLED TO AIR CLEANER ASSEMBLY GROUP.	-1
