AFE75-B 980E-5 S/N A50006 - A50007 TECK

Komatsu parts book diagram for AFE75-B 980E-5 S/N A50006 - A50007 TECK: EXHAUST PIPING - DOUBLE WALL 4/4

? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	58B-02-10070	GASKET	2
	?	58B-02-10080	GASKET	2
	?	EH9397	CLAMP ASSEMBLY	2
	?	EK6240	MOUNT	4
	?	EK6241	PLATE, BENT	4
	?	MM0461	FLAT WASHER - M10	24
	?	MM0605	CAPSCREW - M10 X 1.50 X 25	24
	?	PC0760	CLAMP, V-BAND	2
	?	TR4735	LOCKWASHER - 3/4"	32
	?	TR8960	NUT - 3/4" - 10NC	32
	?	VF8334	CAPSCREW - 3/4" - 10NC X 2 3/4"	32

Komatsu AFE75-B 980E-5 S/N A50006 - A50007 TECK parts catalog PDF

EXHAUST PIPING - DOUBLE WALL 4/4 (68725) in AFE75-B 980E-5 S/N A50006 - A50007 TECK. Diagram image and parts list.
