AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE8070	COLLAR	2
?	BF2596	NUT	2
?	BF2594	PLUNGER	2
?		SEAL, WIPER (1)	2
?	VE8533	SCREW	1
?	BF2595	PACKING	6
?	BF2598	RING, GLYD	2
?	VE9403	SPRING, PLUNGER RETURN (1)/(2)	2
?	BF2597	SEAT, SPRING (2)	2
?	EF5752	SPOOL, REGULATING	2
?		SLEEVE (1)	2
?	VE9401	SPRING, SPOOL (1)/(2)	2
?		PLUNGER (1)	2
?		SEAL (1)	2
?		PACKING (1)	1
?	VE9418	PLUG	1
?	C1546	FLAT WASHER - 1/4"	4
?		CAPSCREW (1)	4
?	VE9421	RETAINER, SLEEVE	1
?		BODY	1
?		SEAL (1)	2
?	EF3449	PLUG, ORIFICE - .045	1
?	VE8080	SPRING, REGULATOR (2)	2
?	BF2599	SPRING, REGULATOR (2)	2
?	BF2593	SEAT - STAGING (2)	2
?	BF2592	PACKING	2
?	BF2591	STUD	2
?		RING, BACKUP (1)	2
?		SEAL (1)	2
?		RING, BACKUP (1)	2
?	WA0019	O-RING	2
?		RING, BACKUP (1)	4
?		NOTE: (1) NOT SERVICED SEPARATELY.	-1
?	AK5063	(2) INCLUDED IN AK5063 SPRING KIT.	-1

Komatsu AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA parts catalog PDF

BRAKE VALVE SUB-ASSEMBLY 2/2 XA2704 (60066) in AFE73-B 980E-4 S/N A40031 - A40032 ANTAMINA. Diagram image and parts list.
