AFE69-F 730E-8 S/N A40018 - A40034 NATALKA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58D-80-11860	BRACKET A., BOX MOUNT	1
?	EM8447	PLATE BENT	1
?	MM0178	NUT - M10 X 1.50	1
?	MM0459	FLAT WASHER - M6	2
?	MM0469	LOCKWASHER - M6	4
?	MM0471	LOCKWASHER - M10	4
?	MM0582	CAPSCREW - M6 X 1.00 X 20	5
?	MM0604	CAPSCREW - M10 X 1.50 X 20	4
?	MM0605	CAPSCREW - M10 X 1.50 X 25	3
?	MM0713	FLAT WASHER - M10 (HARDENED)	2
?	PB7929	PLUG, BUTTON	5
?	PB9310	PLUG, BUTTON	2
?	WB1301	CLAMP, CUSHIONED - 1/4"	1
?	WB1304	CLAMP, CUSHIONED - 9/16"	3
?	01571-01016	SEAT	1

Komatsu AFE69-F 730E-8 S/N A40018 - A40034 NATALKA parts catalog PDF

JUNCTION BOX ASSEMBLY - LH 58D-00-10390 (45362) in AFE69-F 730E-8 S/N A40018 - A40034 NATALKA. Diagram image and parts list.
