AFE69-F 730E-8 S/N A40018 - A40034 NATALKA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58D-03-80110	TANK, TOP	1
?	58D-03-80120	TANK, CENTER	1
?	58D-03-80130	TANK, BOTTOM	1
?	58D-03-80160	TIE, TENSION	2
?	58D-03-80150	MEMBER, SIDE	1
?	58D-03-80140	MEMBER, SIDE	1
?	TL5327	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	C1540	LOCKWASHER - 1/2"	32
?	VE3461	NUT - 1/2" - 13NC	24
?	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	XA5911	AIR BAFFLE, BOTTOM	4
?	XA5910	AIR BAFFLE, TOP	4
?	VE3460	CAPSCREW - 1/2" - 13NC X 1"	16
?	XA5351	RIVET	4
?		NOTE: NS = NOT SHOWN	-1
?	58D-03-00230	TUBE	-1

Komatsu AFE69-F 730E-8 S/N A40018 - A40034 NATALKA parts catalog PDF

RADIATOR, AFTERCOOLER (LTC) 58D-03-80100 (45223) in AFE69-F 730E-8 S/N A40018 - A40034 NATALKA. Diagram image and parts list.
