AFE63-B 960E-1K S/N A50009 - A50010 ANGLO SISHEN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	VC6561	CAPSCREW - 1/2" - 13NC X 1 1/2"	2
?	TR6008	FLAT WASHER - 1/2"	2
?	VM0314	PLUG, O-RING	1
?	PC1531	DUAL RELAY VALVE (SEE INDEX)	1	61000
?	HA8575	HOSE (RIGHT REAR BRAKE APPLY)	1
?	HA7368	HOSE (LEFT REAR BRAKE APPLY)	1
?	HA5913	HOSE	2
?	HA8489	HOSE	1
?	TY8375	SPACER	2
?	WB3092	CLAMP, CUSHION - 7/8"	5
?	WB3093	CLAMP, CUSHION - 1"	1
?	MM0178	NUT - M10 X 1.50	9
?	MM0461	FLAT WASHER - M10	9
?	WB0542	FITTING, ELBOW - 45 DEG	1
?	WB0537	FITTING, 45 DEGREE ELBOW	3
?	HA7990	HOSE	1
?	WB0535	FITTING, ELBOW - 45 DEG	1
?	WB0531	FITTING, ELBOW - 45 DEG	1
?	HA7719	HOSE	1
?	HA7385	HOSE	1
?	WB0574	FITTING, STRAIGHT	1
?	WB1300	CLAMP, CUSHION - 5/8"	1
?	WB0384	FITTING, TEE	2
?	WB0585	FITTING, STRAIGHT	1
?	WB1303	CLAMP, CUSHION - 3/4"	5
?	WB0584	FITTING, STRAIGHT	2
?	WB0593	FITTING, STRAIGHT	1

Komatsu AFE63-B 960E-1K S/N A50009 - A50010 ANGLO SISHEN parts catalog PDF

BRAKE APPLY PIPING - REAR AXLE 2/2 (61626) in AFE63-B 960E-1K S/N A50009 - A50010 ANGLO SISHEN. Diagram image and parts list.
