AFE63-B 960E-1K S/N A50009 - A50010 ANGLO SISHEN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PC2163	FLOW AMPLIFIER	1
?	EL1921	TUBE	1
?	VG9096	O-RING	2
?	TF3237	CLAMP, SPLIT FLANGE - 1 1/4"	4
?	C1609	CAPSCREW - 7/16" - 14NC X 1 1/2"	9
?	C5775	LOCKWASHER - 7/16"	11
?	WB0574	FITTING, STRAIGHT	1
?	EL1920	TUBE	1
?	VG9097	O-RING	4
?	TF8077	CLAMP, SPLIT FLANGE	8
?	C1604	CAPSCREW - 3/8" - 16NC X 1 1/2"	4
?	C0312	LOCKWASHER - 3/8"	16
?	C1603	CAPSCREW - 3/8" - 16NC X 1 1/4"	12
?	WB0537	FITTING, 45 DEGREE ELBOW	1
?	EL1919	TUBE	1
?	EL1918	TUBE	1
?	C1608	CAPSCREW - 7/16" - 14NC X 1"	2
?	PB1255	FLAT WASHER - 7/16"	3
?	WB0584	FITTING, STRAIGHT	3

Komatsu AFE63-B 960E-1K S/N A50009 - A50010 ANGLO SISHEN parts catalog PDF

FLOW AMPLIFIER VALVE PIPING & INSTALLATION (61553) in AFE63-B 960E-1K S/N A50009 - A50010 ANGLO SISHEN. Diagram image and parts list.
