AIR CONDITIONER PIPING & INSTALLATION | AFE47-DH 730E S/N A30375 ALCOA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE47-DH 730E S/N A30375 ALCOA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VY9850	MOUNT, RUBBER	4
?	EK8764	MOUNT, CONDENSER	1
?	C1616	CAPSCREW - 1/2" - 13NC X 2.00	4
?	DA0557	WASHER	8
?	HA7880	HOSE	1
?	WA1731	O-RING - 5/16"	4
?	HA7881	HOSE	1
?	PC1804	SWITCH, TRINARY	1
?	PB7619	ADAPTER	1
?	PC1341	BRACKET	1
?	PB8689	RECEIVER DRIER	1
?	MM0027	CAPSCREW - M6 X 1.00 X 25	4
?	MM0459	FLAT WASHER - M6	4
?	WB1304	CLAMP, CUSHION - 9/16"	10
?	WB3093	CLAMP, CUSHION - 1.00"	10
?	MM0461	FLAT WASHER - M10	13
?	MM0178	NUT - M10 X 1.50	13
?	MM0471	LOCKWASHER - M10	13
?	HA8070	HOSE	1
?	WA1733	O-RING - 9/16"	1
?	PC1830	ACCUMULATOR	1
?	WA1056	CLAMP, T-BOLT	2
?	WB3091	CLAMP, CUSHION - 11/16"	3
?	TR4436	FLAT WASHER - 3/8" (ZINC)	1
?	HA8071	HOSE	1
?	892124C1	SPACER - 5/8"	1
?	C1605	CAPSCREW - 3/8" - 16NC X 1.75	1
?	C1613	CAPSCREW - 1/2" - 13NC X 1.25	12
?	WA4728	FLAT WASHER - 1/2" (HARDENED) (ZINC)	24
?	DF3500	LOCKNUT - 1/2" - 13NC	12
?	EK8720	CONDENSER	1
?	HA7185	HOSE	1
?	WB1027	O-RING - 11/16"	2
?	WA1732	O-RING - 7/16"	1
