AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE9566	DRIVE SHAFT W/ SPLINE	1
?	VE9568	BEARING	1
?	VE9570	RING, RETAINING	1
?	VE9569	RING, RETAINING	1
?	VE9535	EYE BOLT	2
?	VE9545	NAME PLATE	1
?	VE9544	DRIVE SCREW	8
?	VE9542	NAME PLATE	1
?	VE9538	PLUG	3
?	VE9540	O-RING	3
?	VE9543	NAME PLATE	1
?	VE9597	STEM	1
?	VE9598	O-RING	1
?	VE9595	GLAND	1
?	58E-98-00050	O-RING (1)	2
?	BF3733	JAM NUT	1
?	VE9534	BEARING, RETAINER PIN	2
?	VE9546	O-RING	3
?	VE9562	PIN, SWASH BLOCK	2
?	VE9530	HOUSING, PUMP	1
?	VE9567	RETAINER, SEAL	1
?	BF0293	O-RING	2
?	VE9536	PLUG	1
?	VE9532	SEAL, SHAFT	1
?	VE9607	PLUG, HOLLOW HEX	1
?	58E-98-00000	NOTE: (1) INCLUDED IN 58E-98-00000 PUMP SEAL KIT.	-1

Komatsu AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN parts catalog PDF

STEERING PUMP HOUSING (FRONT) 58B-60-00080 (41335) in AFE75-M 980E-5 S/N A50044 - A50046, A50048 COPPER MOUNTAIN. Diagram image and parts list.
