STEERING AND ROD | PC3000-1 S/N 06194 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC3000-1 S/N 06194

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	900 005 40	Steering and rod	1
?	900 006 40	Steering consist. of fig-nos: 20 - 23	1
?	494 458 40	Rod consist. of fig-nos: 22, 23, 25 - 27	1
?	482 003 40	Pin (standard)	1
?	900 011 40	Pin (standard)	1
?	900 008 40	Pin (standard)	1
?	621 072 40	Pin	1
?	218 520 40	Pin lock	2
?	534 072 99	Cotter pin	1
?	900 024 40	Shackle	2
?	900 021 40	Catch	4
?	319 186 99	Bolt	8
?	500 804 98	Disc	8
?	925 577 40	Cover assy.	1
?	925 579 40	Cover assy.	1
?	307 209 99	Bolt	2
?	925 576 40	Plate	2
?	900 044 40	Steering	1
?	636 156 40	Bushing	2
?	575 786 40	Seal ring	6
?	004 860 98	Grease nipple	5
?	494 459 40	Rod	1
?	636 158 40	Bushing	2
?	636 157 40	Bushing	1
