Diagram image 1 of 2

PC3000-6 S/N 06217

? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 06217

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	769 397 73	Lube pump assy.	1
?	766 995 73	Cylinder assy. with control block	1
?	332 334 99	Nut	4
?	340 909 99	Washer	4
?	766 996 73	Suction tube assy.	1
?	766 997 73	Spacer rod	4
?	766 998 73	Adapter	1
?	766 999 73	Hydr.-cylinder	1
?	769 000 73	Flow control valve	1
?	769 001 73	Pressure reducing valve	1
?	769 027 73	H.P. Hose	1
?	769 002 73	Bolt	1
?	769 003 73	Adapter	1
?	769 004 73	Piston rod	1
?	769 005 73	Bushing	1
?		O-ring These parts are not sold separately	1
?		V-seal These parts are not sold separately	1
?		Supporting disc These parts are not sold separately	1
?		Circlip These parts are not sold separately	1
?	769 006 73	Housing	1
?	769 007 73	Plug	1
?	769 008 73	Adapter	1
?		Packing These parts are not sold separately	2
?	769 009 73	Valve seat	1
?	769 010 73	Ball	1
?	769 011 73	Ball retainer	1
?	764 137 73	Adapter	1
?		O-ring These parts are not sold separately	1
?	769 012 73	Pipe	1
?	769 013 73	Adapter	1
?		Cotter pin These parts are not sold separately	2
?	769 014 73	Rod	1
?	769 015 73	Adapter	1
?	769 010 73	Ball	1
?	769 016 73	Ball	1
?	769 017 73	Pin	1
?	769 018 73	Piston assy.	1
?		O-ring These parts are not sold separately	1
?	769 019 73	Cylinder barrel	1
?		Circlip These parts are not sold separately	1
?		Valve guide These parts are not sold separately	1
?	769 020 73	Piston rod, set	1
?		Cotter pin These parts are not sold separately	1
?	769 021 73	Retaining ring	1
?	769 022 73	Valve	1
?	769 023 73	Valve seat	1
?	769 024 73	Piston nut	1
?	769 025 73	End pipe	1
?	769 026 73	Repair kit to fig-no. 05 conist. of fig-nos. 16-19,23, 28,31,38,40,41,43	1
?	793 533 73	Seal kit to fig-no. 02	1
