01 |
924 900 40
|
Hydraulic cylinder (standard) |
1 |
|
|
|
|
01 |
934 615 40
|
Hydraulic cylinder (cold weather design) |
1 |
|
|
|
|
03 |
|
Cylinder barrel |
1 |
|
|
|
|
05 |
907 022 40
|
Seal ring |
4 |
|
|
|
|
06 |
004 860 98
|
Grease nipple |
3 |
|
|
|
|
07 |
792 429 73
|
Piston rod assy. incl. fig-nos. 05,06,08,09 |
1 |
|
|
|
|
08 |
|
Piston rod |
1 |
|
|
|
|
09 |
627 572 40
|
Freeze-in bushing |
1 |
|
|
|
|
10 |
926 859 40
|
Sealing flange incl. fig-nos. 11,12+17 |
1 |
|
|
|
|
11 |
|
Flanged bush |
1 |
|
|
|
|
12 |
926 899 40
|
Bearing bush (no field repair item) |
1 |
|
|
|
|
13 |
659 097 40
|
Piston assy. incl. fig-nos. 14+15 |
1 |
|
|
|
|
14 |
|
Piston |
1 |
|
|
|
|
15 |
445 393 40
|
Liner (no field repair item) |
1 |
|
|
|
|
16 |
947 190 40
|
Groove nut |
1 |
|
|
|
|
17 |
342 698 99
|
Circlip |
1 |
|
|
|
|
19 |
269 475 40
|
Sealing element (standard) |
1 |
|
|
|
|
19 |
896 587 40
|
Sealing element (cold weather design) |
1 |
|
|
|
|
20 |
256 248 40
|
O-ring (standard) |
1 |
|
|
|
|
20 |
515 788 98
|
O-ring (cold weather design) |
1 |
|
|
|
|
21 |
256 245 40
|
Piston guide ring |
5 |
|
|
|
|
22 |
269 785 40
|
Piston guide strap |
2 |
|
|
|
|
23 |
440 675 40
|
O-ring (standard) |
1 |
|
|
|
|
23 |
510 414 98
|
O-ring (cold weather design) |
1 |
|
|
|
|
24 |
655 589 40
|
Support ring |
2 |
|
|
|
|
26 |
517 018 98
|
O-ring (standard) |
1 |
|
|
|
|
26 |
502 670 98
|
O-ring (cold weather design) |
1 |
|
|
|
|
27 |
907 666 40
|
Support ring |
1 |
|
|
|
|
29 |
318 798 99
|
Bolt (standard) |
18 |
|
|
|
|
29 |
511 722 98
|
Screw (cold weather design) |
18 |
|
|
|
|
31 |
354 389 99
|
Feather key |
1 |
|
|
|
|
32 |
947 188 40
|
Threaded pin |
1 |
|
|
|
|
33 |
7075120810
|
Buffer ring |
1 |
|
|
|
|
34 |
7075120080
|
Rod seal (standard) |
1 |
|
|
|
|
34 |
7075120730
|
Rod seal (cold weather design) |
1 |
|
|
|
|
35 |
5816392670
|
Dust seal |
1 |
|
|
|
|
36 |
517 563 98
|
Circlip |
1 |
|
|
|
|
|$$38 |
767 498 73
|
Seal kit piston consist. of fig nos: 19-24 (standard) |
1 |
|
|
|
|
|$$39 |
793 480 73
|
Seal kit piston rod consist. of fig.-nos: 26,27,33-35 (standard) |
1 |
|
|
|
|
|$$40 |
794 967 73
|
Seal kit piston consist. of fig nos: 19-24 (cold weather design) |
1 |
|
|
|
|
|$$41 |
794 968 73
|
Seal kit piston rod consist. of fig.-nos: 26,27,33-35 (cold weather design) |
1 |
|
|
