01 |
924 910 40
|
Hydraulic cylinder (standard) |
1 |
|
|
|
|
01 |
934 625 40
|
Hydraulic cylinder (cold weather design) |
1 |
|
|
|
|
02 |
792 136 73
|
Cylinder barrel assy. |
1 |
|
|
|
|
03 |
430 867 40
|
Flanged bush |
2 |
|
|
|
|
04 |
907 019 40
|
Seal ring |
2 |
|
|
|
|
05 |
004 860 98
|
Grease nipple |
4 |
|
|
|
|
06 |
792 143 73
|
Piston rod assy. incl. fig-nos. 04,05,07,08 |
1 |
|
|
|
|
07 |
|
Piston rod |
1 |
|
|
|
|
08 |
882 157 40
|
Flanged bush |
2 |
|
|
|
|
09 |
924 983 40
|
Sealing flange assy. incl. fig-nos. 10-12 (finish work after bush is installed) |
1 |
|
|
|
|
10 |
|
Flanged bush |
1 |
|
|
|
|
11 |
929 237 40
|
Bearing bush |
1 |
|
|
|
|
12 |
342 688 99
|
Circlip |
1 |
|
|
|
|
13 |
460 338 40
|
Piston |
1 |
|
|
|
|
14 |
947 199 40
|
Groove nut |
1 |
|
|
|
|
17 |
202 702 40
|
Seal ring |
1 |
|
|
|
|
18 |
202 703 40
|
O-ring (standard) |
1 |
|
|
|
|
18 |
516 342 98
|
O-ring (cold weather design) |
1 |
|
|
|
|
19 |
255 760 40
|
Piston guide ring |
4 |
|
|
|
|
20 |
324 952 40
|
Piston guide strap |
2 |
|
|
|
|
21 |
7075117030
|
Rod seal |
1 |
|
|
|
|
21 |
7075117730
|
Rod seal (cold weather design) |
1 |
|
|
|
|
22 |
7075617510
|
Dust seal |
1 |
|
|
|
|
23 |
007 632 98
|
O-ring (standard) |
1 |
|
|
|
|
23 |
932 669 40
|
O-ring (cold weather design) |
1 |
|
|
|
|
24 |
226 431 40
|
Support ring |
1 |
|
|
|
|
25 |
000 219 98
|
O-ring (standard) |
1 |
|
|
|
|
25 |
510 481 98
|
O-ring (cold weather design) |
1 |
|
|
|
|
26 |
256 724 40
|
Spiral backring |
2 |
|
|
|
|
27 |
354 389 99
|
Feather key |
1 |
|
|
|
|
28 |
319 354 99
|
Bolt |
20 |
|
|
|
|
28 |
512 890 98
|
Screw (cold weather design) |
20 |
|
|
|
|
29 |
319 288 99
|
Bolt |
8 |
|
|
|
|
30 |
947 184 40
|
Threaded pin |
1 |
|
|
|
|
32 |
506 581 98
|
Plug |
1 |
|
|
|
|
33 |
356 209 40
|
Flange seal |
1 |
|
|
|
|
34 |
517 456 98
|
Circlip |
1 |
|
|
|
|
35 |
7075117810
|
Buffer ring |
1 |
|
|
|
|
|$$39 |
697 677 73
|
Seal kit - piston consist. of fig-nos: 17-20,25,26 (standard) |
1 |
|
|
|
|
|$$40 |
793 482 73
|
Seal kit - piston rod consist. of fig-nos: 21-24, 35 (standard) |
1 |
|
|
|
|
|$$41 |
794 977 73
|
Seal kit - piston consist. of fig-nos: 17-20,25,26 (cold weather design) |
1 |
|
|
|
|
|$$42 |
794 978 73
|
Seal kit - piston rod consist. of fig-nos: 21-24, 35 (cold weather design) |
1 |
|
|
