Diagram image 1 of 2

PC3000-6E S/N 06262

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6E S/N 06262

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	928 059 40	Pipe assy.	1	InternKon: 928 000 40 / 1
?	928 058 40	Pipe assy.	2	InternKon: 928 000 40 / 2
?	928 057 40	Pipe assy.	1	InternKon: 928 000 40 / 3
?	928 056 40	Pipe assy.	2	InternKon: 928 000 40 / 4
?	928 005 40	Pipe assy.	1	InternKon: 928 000 40 / 5
?	928 006 40	Pipe assy.	1	InternKon: 928 000 40 / 6
?	928 007 40	Pipe assy.	1	InternKon: 928 000 40 / 7
?	928 008 40	Pipe assy.	1	InternKon: 928 000 40 / 8
?	928 009 40	Pipe assy.	1	InternKon: 928 000 40 / 9
?	928 010 40	Pipe assy.	1	InternKon: 928 000 40 / 10
?	933 812 40	Pipe assy.	1	InternKon: 928 000 40 / 11
?	928 012 40	Pipe assy.	1	InternKon: 928 000 40 / 12
?	928 015 40	Pipe assy.	1	InternKon: 928 000 40 / 15
?	928 017 40	Pipe assy.	1	InternKon: 928 000 40 / 17
?	928 018 40	Pipe assy.	1	InternKon: 928 000 40 / 18
?	928 019 40	Pipe assy.	1	InternKon: 928 000 40 / 19
?	928 020 40	Pipe assy.	1	InternKon: 928 000 40 / 20
?	928 021 40	Pipe assy.	1	InternKon: 928 000 40 / 21
?	928 022 40	Pipe assy.	1	InternKon: 928 000 40 / 22
?	928 023 40	Pipe assy.	1	InternKon: 928 000 40 / 23
?	928 024 40	Pipe assy.	1	InternKon: 928 000 40 / 24
?	928 025 40	Pipe assy.	1	InternKon: 928 000 40 / 25
?	928 026 40	Pipe assy.	1	InternKon: 928 000 40 / 26
?	928 027 40	Pipe assy.	1	InternKon: 928 000 40 / 27
?	928 029 40	Pipe assy.	1	InternKon: 928 000 40 / 29
?	928 030 40	Pipe assy.	1	InternKon: 928 000 40 / 30
?	928 031 40	Pipe assy.	1	InternKon: 928 000 40 / 31
?	928 032 40	Pipe assy.	1	InternKon: 928 000 40 / 32
?	928 033 40	Pipe assy.	1	InternKon: 928 000 40 / 33
?	928 034 40	Pipe assy.	1	InternKon: 928 000 40 / 34
?	928 035 40	Pipe assy.	1	InternKon: 928 000 40 / 35
?	928 037 40	Pipe assy.	1	InternKon: 928 000 40 / 37
?	928 038 40	Pipe assy.	1	InternKon: 928 000 40 / 38
?	928 039 40	Pipe assy.	1	InternKon: 928 000 40 / 39
?	928 040 40	Pipe assy.	1	InternKon: 928 000 40 / 40
?	928 041 40	Pipe assy.	1	InternKon: 928 000 40 / 41
?	928 042 40	Pipe assy.	1	InternKon: 928 000 40 / 42
?	928 043 40	Pipe assy.	1	InternKon: 928 000 40 / 43
?	928 044 40	Pipe assy.	1	InternKon: 928 000 40 / 44
?	928 045 40	Pipe assy.	1	InternKon: 928 000 40 / 45
?	928 046 40	Pipe assy.	1	InternKon: 928 000 40 / 46
?	928 047 40	Pipe assy.	1	InternKon: 928 000 40 / 47
?	928 048 40	Pipe assy.	1	InternKon: 928 000 40 / 48
?	928 050 40	Pipe assy.	5	InternKon: 928 000 40 / 50
?	928 051 40	Pipe assy.	1	InternKon: 928 000 40 / 51
?	928 052 40	Pipe assy.	1	InternKon: 928 000 40 / 52
?	928 054 40	Pipe assy.	1	InternKon: 928 000 40 / 54
?	928 055 40	Pipe assy.	1	InternKon: 928 000 40 / 55
?	933 816 40	Pipe assy.	1	InternKon: 928 000 40 / 62
?	928 099 40	Marking strips, top	1	InternKon: 928 000 40 / 85
?	928 097 40	Marking strips, lower	1	InternKon: 928 000 40 / 86
?	928 098 40	Marking strips, center	1	InternKon: 928 000 40 / 87
?	933 818 40	Base plate	1	InternBDB: S355J2G3 \| InternKon: 928 000 40 / 88
?	180 325 40	Base plate	7	InternBDB: G 342/1 3/8" Rexroth \| InternKon: 928 000 40 / 89
?	928 004 40	Rib	2	InternBDB: S355J2G3 \| InternKon: 928 000 40 / 90
?	928 003 40	Bridge	1	InternBDB: S355J2G3 \| InternKon: 928 000 40 / 91
?	932 609 40	Pressure switch	1	InternBDB: 7 bar SchlieЯer G 1/4" SUKO \| InternKon: 934 928 40 / 1
?	515 460 40	Bonded seal	1	InternBDB: 14,00X18,70X1 NSABusak+Shamb \| InternKon: 934 928 40 / 2
?	894 538 40	Pressure switch assy. consist. of fig-nos. 114+115	1	InternBDB: 22 bar SchlieЯer G 1/4" SUKO \| InternKon: 928 000 40 / 111
?	934 928 40	Pressure switch assy. consist. of fig-nos. 95+96	2	InternBDB: 7 bar SchlieЯer G 1/4" SUKO \| InternKon: 928 000 40 / 112
?	371 949 99	Union	3	InternBDB: MAV-EV 12-LR \| InternKon: 928 000 40 / 113
?	634 566 40	Pressure switch	1	InternBDB: 22 bar SchlieЯer G 1/4" SUKO \| InternKon: 894 538 40 / 1
?	515 460 40	Bonded seal	1	InternBDB: 14,00X18,70X1 NSABusak+Shamb \| InternKon: 894 538 40 / 2
?	933 822 40	Pipe assy.	1	InternKon: 928 000 40 / 122
?	933 823 40	Pipe assy.	1	InternKon: 928 000 40 / 123
?	933 824 40	Pipe assy.	1	InternKon: 928 000 40 / 124
?	933 825 40	Pipe assy.	1	InternKon: 928 000 40 / 125
?	933 826 40	Pipe assy.	1	InternKon: 928 000 40 / 126
?	933 827 40	Pipe assy.	1	InternKon: 928 000 40 / 127
?	907 819 40	Union	7	InternBDB: ET 12L SA2 OMD \| InternKon: 928 000 40 / 130
?	516 167 98	Socket	4	InternBDB: L 12 / DIN 3943 \| InternKon: 928 000 40 / 131
?	516 174 98	Socket	15	InternBDB: L 12 / DIN 3944 \| InternKon: 928 000 40 / 132
?	516 157 98	Socket	5	InternBDB: L 12 / DIN 3942 \| InternKon: 928 000 40 / 133
?	374 430 99	Union	15	InternBDB: SDS-L12XM16x1,5 ISO 8434 \| InternKon: 928 000 40 / 134
?	371 459 99	Union	26	InternBDB: SDS-L12XG 3/8A \| InternKon: 928 000 40 / 135
?	509 267 98	Nut	44	InternBDB: M18x1,5 / DIN 80705 \| InternKon: 928 000 40 / 136
?	634 499 40	Union	1	InternBDB: K-L 12 / ISO 8434 \| InternKon: 928 000 40 / 137
?	511 015 98	Union	1	InternBDB: T-L 12 / ISO 8434 \| InternKon: 928 000 40 / 138
?	502 752 98	Coupling	1	InternBDB: 12-L / WN 341 985 40 \| InternKon: 928 000 40 / 140
?	516 962 98	Union	37	InternBDB: BH-L 12 / ISO 8434 \| InternKon: 928 000 40 / 141
?	509 271 98	Nut	2	InternBDB: M26x1,5 / DIN 80705 \| InternKon: 928 000 40 / 142
?	513 854 98	Bolt	4	InternBDB: M12x25 / DIN 933 \| InternKon: 928 000 40 / 150
?	307 732 99	Bolt	23	InternBDB: M6x25 / DIN 933 \| InternKon: 928 000 40 / 151
?	507 025 98	Nut	29	InternBDB: M 6 / DIN 985 \| InternKon: 928 000 40 / 153
?	509 488 98	Nut	4	InternBDB: M 12 / DIN 985 \| InternKon: 928 000 40 / 154
?	340 467 99	Washer	4	InternBDB: A 13 / DIN 125 \| InternKon: 928 000 40 / 155
?	255 694 40	Plug	2	InternBDB: Vsti R 3/8 ED \| InternKon: 928 000 40 / 157
?	907 820 40	Shuttle valve	2	InternKon: 928 000 40 / 160
?	343 873 40	Shuttle valve	4	InternBDB: 12-L 690997 Voss \| InternKon: 928 000 40 / 161
?	414 370 40	Valve	3	InternBDB: NG 6 (MO-7204) MH3WA 06 UG1X/004MO2 \| InternKon: 928 000 40 / 162
?	932 617 40	4/2-Directional spool valve	4	InternBDB: DG4V-3-8BL-M-KU-H7-60 \| InternKon: 928 000 40 / 163
?	932 616 40	4/2-Directional spool valve	3	InternBDB: DG4V-3-0A-M-KU-H7-60 \| InternKon: 928 000 40 / 164
?	308 544 99	Bolt	6	InternBDB: M6x80 8.8/ DIN 931 \| InternKon: 928 000 40 / 165
?	515 865 98	Socket	4	InternBDB: GRZ 18/12-PL / WN 655 910 40 \| InternKon: 928 000 40 / 167
?	511 135 98	Union	4	InternBDB: T-L 18 \| InternKon: 928 000 40 / 169
?	516 159 98	Socket	3	InternBDB: SWE-L 18 \| InternKon: 928 000 40 / 170
?	634 303 40	Union	1	InternBDB: Red 18/12-PL / OMD Ermeto \| InternKon: 928 000 40 / 171
?	371 276 99	Union nut	10	InternBDB: N-L 18 / ISO 8434 \| InternKon: 928 000 40 / 172
?	906 349 40	Olive	10	InternBDB: ES-4L18 WN65593940 \| InternKon: 928 000 40 / 173
?	371 274 99	Union nut	100	InternBDB: N-L 12 / ISO 8434 \| InternKon: 928 000 40 / 174
?	906 347 40	Olive	100	InternBDB: ES-4S12 WN65593940 \| InternKon: 928 000 40 / 175
?	308 436 99	Bolt	4	InternBDB: M12x75 /931 \| InternKon: 925 161 40 / 200
?	510 741 98	Resilient sleeve	4	InternBDB: 13/25x50 \| InternKon: 925 161 40 / 201
?			-2
?			-2
?			-2
?	634 566 40	Pressure switch	1	InternBDB: DRUCKSCHALTER 0166 415 03 1059 22,0 BAR \| InternKon: 925 161 40 / 1
?	515 460 40	Seal ring	1	InternBDB: FLACHDICHTG 14,00X18,70X1 NSA \| InternKon: 925 161 40 / 2

Komatsu PC3000-6E S/N 06262 parts catalog PDF

PIPES - PILOT CONTROL PLATE (BBE) (485-1882f) in PC3000-6E S/N 06262. Diagram image and parts list.
