PC3000-6E S/N 06262

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	924 900 40	Hydraulic cylinder (standard)	1	InternBDB: KMG 320/200x2000 (3600) \| InternKon: 934 615 40 / 1
?	934 615 40	Hydraulic cylinder (cold weather design)	1	InternBDB: KMG 320/200x2000 (3600) \| InternKon: 934 615 40 / 1
?		Cylinder barrel	1	InternBDB: 659 092 40 \| InternKon: 934 615 40 / 1
?	907 022 40	Seal ring	4	InternBDB: RXYD - 091603T46 170/7x4 \| InternKon: 934 615 40 / 7
?	004 860 98	Grease nipple	3	InternBDB: AR 1/4 / WN 011 207 99 \| InternKon: 934 615 40 / 23
?	792 429 73	Piston rod assy. incl. fig-nos. 05,06,08,09	1	InternBDB: E-ST
?		Piston rod	1	InternBDB: 909 307 40 \| InternKon: 934 615 40 / 2
?	627 572 40	Freeze-in bushing	1	InternKon: 934 615 40 / 6
?	926 859 40	Sealing flange incl. fig-nos. 11,12+17	1	InternKon: 934 615 40 / 3
?		Flanged bush	1	InternBDB: 926 858 40 \| InternKon: 926 859 40 / 1
?	926 899 40	Bearing bush (no field repair item)	1	InternKon: 926 859 40 / 2
?	659 097 40	Piston assy. incl. fig-nos. 14+15	1	InternKon: 934 615 40 / 4
?		Piston	1	InternBDB: 659 098 40 \| InternKon: 659 097 40 / 1
?	445 393 40	Liner (no field repair item)	1	InternKon: 659 097 40 / 2
?	947 190 40	Groove nut	1	InternKon: 934 615 40 / 5
?	342 698 99	Circlip	1	InternBDB: 225x5 / DIN 472 \| InternKon: 926 859 40 / 3
?	269 475 40	Sealing element (standard)	1	InternKon: 934 615 40 / 8
?	896 587 40	Sealing element (cold weather design)	1	InternBDB: TURCON-GLYD-RING PT-08- 03200-T46 \| InternKon: 934 615 40 / 8
?	256 248 40	O-ring (standard)	1	InternBDB: 291,47x7,0 B NB70 / WN 011 745 99 \| InternKon: 934 615 40 / 9
?	515 788 98	O-ring (cold weather design)	1	InternBDB: O-RING 291,47X 7,00B N7T40 WN 01174599 \| InternKon: 934 615 40 / 9
?	256 245 40	Piston guide ring	5	InternKon: 934 615 40 / 10
?	269 785 40	Piston guide strap	2	InternKon: 934 615 40 / 11
?	440 675 40	O-ring (standard)	1	InternBDB: 202,57 x 5,33B \| InternKon: 934 615 40 / 17
?	510 414 98	O-ring (cold weather design)	1	InternBDB: O-RING 202,57X 5,33B N7T40 KALTZ WN 01174599 \| InternKon: 934 615 40 / 17
?	655 589 40	Support ring	2	InternBDB: 200,0x208,6x1,7 \| InternKon: 934 615 40 / 18
?	517 018 98	O-ring (standard)	1	InternBDB: 307,0x7,0 B NB70 \| InternKon: 934 615 40 / 15
?	502 670 98	O-ring (cold weather design)	1	InternBDB: O-RING 304,17X 7,00B N7T40 KALTZ WN 01174599 \| InternKon: 934 615 40 / 15
?	907 666 40	Support ring	1	InternBDB: 320x308,4x1,25 \| InternKon: 934 615 40 / 16
?	318 798 99	Bolt (standard)	18	InternBDB: M30x180 / DIN 912 \| InternKon: 934 615 40 / 21
?	511 722 98	Screw (cold weather design)	18	InternBDB: ZYLSHR M30X180 10.9 KALTZ DIN 00912 \| InternKon: 934 615 40 / 21
?	354 389 99	Feather key	1	InternBDB: A 20x12x70 / DIN 6885 \| InternKon: 934 615 40 / 19
?	947 188 40	Threaded pin	1	InternBDB: M16x50 \| InternKon: 934 615 40 / 22
?	907 669 40	Buffer ring	1	InternBDB: 200x225x9,6 \| InternKon: 934 615 40 / 12
?	907 668 40	Rod seal (standard)	1	InternBDB: 200x225x20,0 \| InternKon: 934 615 40 / 13
?	932 900 40	Rod seal (cold weather design)	1	InternBDB: ROD SEAL 200X225,0X20,0 A903 19YF IUY \| InternKon: 934 615 40 / 13
?	907 667 40	Dust seal	1	InternBDB: 200x216x8,0 \| InternKon: 934 615 40 / 14
?	517 563 98	Circlip	1	InternBDB: A215 / WN 010 718 99 \| InternKon: 934 615 40 / 20
?	767 498 73	Seal kit piston consist. of fig nos: 19-24 (standard)	1
?	793 480 73	Seal kit piston rod consist. of fig.-nos: 26,27,33-35 (standard)	1
?	794 967 73	Seal kit piston consist. of fig nos: 19-24 (cold weather design)	1
?	794 968 73	Seal kit piston rod consist. of fig.-nos: 26,27,33-35 (cold weather design)	1

Komatsu PC3000-6E S/N 06262 parts catalog PDF

HYDR.-CYLINDER (485-4075g) in PC3000-6E S/N 06262. Diagram image and parts list.
